Embedded Boards based on Celeron™ / Socket FCBGA 1170 [ top ]

Supermicro's motherboards based on Intel® Celeron™ processor J1000 series System-on-Chip are well-suited for server, storage, networking, and embedded appliance market.

Product Model Quick View Form Factor / Chipset Memory HDD Other Key Features
X10SBA   X10SBA Mini-ITX / SoC, J1900 8GB DDR3L non-ECC 4x SATA3
2x SATA2
PCIe x2
1 x USB 3.0
4-pin 12V DC input or ATX
X10SBA-L   X10SBA-L Mini-ITX / SoC, J1900 8GB DDR3L non-ECC 2x SATA2 PCIe x2
1 x USB 3.0
4-pin 12V DC input or ATX





Embedded Boards based on Haswell / Socket H3 (LGA 1150) [ top ]

Supermicro's single processor Socket H3 designs feature the Intel® C226, Q87, H81 embedded chipset which support the Xeon E3-1200 V3 and 4th Gen Core i3/i5/i7 processor family. With outstanding features that include up to 32GB of fast DDR3 DRAM in 4 DIMMS, onboard IPMI or vPro, USB 3.0, PCI-E 3.0 and SATA 3.0 (6Gbps) HDD. With support for next generation graphics controller, 4K HD graphics resolution and 3 displays with HDMI, DP, VGA and DVI ports. Designed with performance, reliability, manageability and long life in mind Supermicro's single processor motherboards are the perfect solution for ATM, Kiosk, NVR/DVR Surveillance, Storage or Server appliance and many other embedded applications.

Product Model Quick View Form Factor / Chipset Memory HDD Other Key Features
X10SLQ   X10SLQ uATX / Q87 32GB DDR3 non-ECC, 4 UDIMM 6 SATA3
vPro AMT, 1 Mini-PCI-E w/ mSATA support
X10SLQ-L   X10SLQ-L uATX / Q87 16GB DDR3 non-ECC, 2 UDIMM 5 SATA3
vPro AMT
X10SLH-F

X10SLH-F uATX / C226 32GB DDR3 ECC
4 UDIMM
6 SATA3 Intel i210AT GbE, IPMI, Aspeed AST2400 Video
X10SLV   X10SLV Mini-ITX / H81 16GB DDR3 2x SATA3
2x SATA2
1 PCI-E 2.0 x16, 1 Mini-PCI-E w/ mSATA support
X10SLV-Q   X10SLV-Q Mini-ITX / Q87 16GB DDR3 4x SATA3 including 1x mSATA 1 PCI-E 3.0 x16, 1 Mini-PCI-E w/ mSATA support





Xeon® E5 Family Boards / Socket R (LGA 2011) [ top ]

Supermicro's single processor Socket R designs feature the Intel® C602J embedded chipset which support the Xeon® E5-2600/1600 and E5-2600/1600 v2 family of high performance processors. Designed with performance, reliability, and long life in mind Supermicro's single processor motherboards are the perfect solution for embedded applications such as medical imaging, scientific equipment, industrial automation, or other embedded applications where performance is most needed. With outstanding features that include up to 512GB DDR3, ultra fast SAS2 storage interface (LSI 2308), dual 10 Gigabit or Gigabit Ethernet, Supermicro's single processor socket R embedded solutions are the perfect choice for any demanding workload.

Product Model Quick View Form Factor Memory HDD Other Key Features
X9SRH-7F

X9SRH-7F ATX 512GB DDR3
8 DIMM slots
2 SATA3, 4 SATA2 IPMI 2.0
Intel i350 GbE
LSI 2308
X9SRH-7TF

X9SRH-7TF ATX 512GB DDR3
8 DIMM slots
2 SATA3, 4 SATA2 IPMI 2.0
Intel X540 10GBase-T
LSI 2308





Xeon® E5 Family Boards / Socket R (LGA 2011) [ top ]

Supermicro's dual processor Socket R designs feature the Intel® C602J embedded chipset which support the Xeon® E5-2600 and E5-2600 v2 family of high performance processors. Designed with performance, reliability, and long life in mind Supermicro's dual processor motherboards are the perfect solution for in embedded applications such as medical imaging, scientific equipment, industrial automation, or in the back end data center cloud where performance is most needed. With outstanding features that include up to 1.5TB DDR3, ultra fast SAS2 storage interface, dual 10 Gigabit or quad Gigabit Ethernet Supermicro's dual processor socket R embedded solutions are the perfect choice for any demanding workload.

Product Model Quick View Form Factor Memory HDD Other Key Features
X9DRD-EF

X9DRD-EF E-ATX 1TB DDR3
16 DIMM slots
2 SATA3,
4 SATA2
Intel i350 GbE
X9DR7-TF+

X9DR7-TF+ E-ATX 1.5TB DDR3
24 DIMM slots
2 SATA3,
4 SATA2,
8 SAS via LSI 2208
Intel X540 10GBase-T
X9DRD-7LN4F

X9DRD-7LN4F E-ATX 1TB DDR3
16 DIMM slots
2 SATA3,
4 SATA2
Intel i350 GbE (4 ports)
8 SAS2 via LSI 2308
X9DRD-7LN4F-JBOD

X9DRD-7LN4F-JBOD E-ATX 1TB DDR3
16 DIMM slots
2 SATA3,
4 SATA2
Intel i350 GbE (4 ports)
8 SAS2 via LSI 2308,
IT mode for SAS2
X9DRL-3F

X9DRL-3F ATX 512GB DDR3
8 DIMM slots
2 SATA3,
4 SATA2,
8 SAS via C606
82574L GbE
Legacy PCI
X9DRL-EF

X9DRL-EF ATX 512GB DDR3
8 DIMM slots
2 SATA3,
4 SATA2
Intel i210 GbE
X9DRL-iF

X9DRL-iF ATX 512GB DDR3
8 DIMM slots
2 SATA3,
8 SATA2
82574L GbE
Legacy PCI
X9DRX+-F

X9DRX+-F Proprietary 1TB DDR3
16 DIMM slots
2 SATA3,
8 SATA2
Intel i350 GbE
11 PCI-E slots





Xeon® E5 Family Boards / Socket B2 (LGA 1356) [ top ]

Supermicro's Dual Processor Socket B2 designs feature the C602/C606 chipset that supports the Xeon E5-2400 Processors. Supermicro's cost optimized socket B2 designs combine the performance-per-watt efficiency of the E5-2400 with legacy PCI support, compact ATX form factors , and up to 192GB of fast DDR3 ECC DRAM. Plus additional features like integrated IPMI remote management, high speed SATA3, and legacy PCI slots. Designed with embedded applications in mind, these boards are ideally suited for use in network security, firewall/gateway, instrumentation, and anywhere compute power, legacy support and standard form factor are a concern.

Product Model Quick View Form Factor Memory HDD Other Key Features
X9DBL-3

X9DBL-3 ATX 192GB DDR3
6 DIMM slots
4 SATA2, 2 SATA3, 8 SAS Audio
2x Intel 82574L GbE
X9DBL-3F

X9DBL-3F ATX 192GB DDR3
6 DIMM slots
4 SATA2, 2 SATA3, 8 SAS IPMI 2.0
2x Intel 82574L GbE
X9DBL-i

X9DBL-i ATX 192GB DDR3
6 DIMM slots
8 SATA2, 2 SATA3 2x Intel 82574L GbE
X9DBL-iF

X9DBL-i ATX 192GB DDR3
6 DIMM slots
8 SATA2, 2 SATA3 IPMI 2.0
2x Intel 82574L GbE





X9SKV Communication Boards / Gladden BGA [ top ]

Supermicro leverages its deep expertise in server technology to bring customers the advanced network security solution with Intel communication chipset 8903 and Gladden Processors. The X9SKV series offer Intel® QuickAssist Technology with hardware accelerator for cryptographic performance. These advanced technology building blocks offer the best communication server or appliance performance with the Intel® Xeon® E3-1225C, E3-1105C v2 and B915C CPUs, up to 4 ECC SODIMMs operating at 1600MHz, USB 2.0, onboard programmable Quad Port bypass GbE LAN using I350-AM4 with SR-IOV support and 2 GbE with two I210AT controllers. Small Form Factor with 9.6" x 7.5" with slot 6 or slot 7 support for flexible Super Chassis selection.

Product Model Quick View Form Factor / Chipset Memory HDD Other Key Features
X9SKV-B915

X9SKV-B915 Flex ATX / Communication Chipset 8903 32GB DDR3 ECC
4 DIMM slots
2 SATA2 Intel i210AT + i350-AM4 GbE, 7 Years
X9SKV-1125

X9SKV-B915 Flex ATX / Communication Chipset 8903 32GB DDR3 ECC
4 DIMM slots
2 SATA2 Intel i210AT + i350-AM4 GbE, 7 Years
X9SKV-1105

X9SKV-B915 Flex ATX / Communication Chipset 8903 32GB DDR3 ECC
4 DIMM slots
2 SATA2 Intel i210AT + i350-AM4 GbE, 7 Years





QM77 Express chipset Boards [ top ]

Supermicro X9SPV-F and X9SPV-LN4F motherboards based on the Mobile Intel QM77 Express chipset support Intel's 3rd Generation Core i7/i5/i3 processors. The compact mini-ITX motherboards are ideal for high-performance, low-power embedded applications, with features that include support for 16GB DDR3 Memory, SATA 3 & SATA 2 HDD/SSD storage with RAID support, 4x Gigabit Ethernet LAN Ports, PCI-E 3.0 x16 slot for added Graphics, Networking or I/O expansion. Compared to the previous generation architecture, this solution delivers 15% more processing performance, up to 50% more 3D graphics performance supporting the latest graphic APIs - DX11, OpenCL 1.1 and OpenGL 3.1 and new features such as Intel® Smart Response Technology enabling increased storage I/O performance with SSD caching.

Product Model Quick View Form Factor Chipset Memory HDD
X9SPV-M4   X9SPV-M4 Mini-ITX Intel QM77 16GB DDR3 2x SATA3
4x SATA2
X9SPV-M4-3QE   X9SPV-M4-3QE Mini-ITX Intel QM77 16GB DDR3 2x SATA3
4x SATA2
X9SPV-M4-3UE   X9SPV-M4-3UE Mini-ITX Intel QM77 16GB DDR3 2x SATA3
4x SATA2
X9SPV-LN4F-3LE   X9SPV-LN4F Mini-ITX Intel QM77 16GB DDR3 2x SATA3
4x SATA2
X9SPV-LN4F-3QE   X9SPV-LN4F Mini-ITX Intel QM77 16GB DDR3 2x SATA3
4x SATA2
X9SPV-F-3610ME   X9SPV-F Mini-ITX Intel QM77 16GB DDR3 2x SATA3
4x SATA2
X9SPV-F-3217UE   X9SPV-F Mini-ITX Intel QM77 16GB DDR3 2x SATA3
4x SATA2





QM67 (Cougar Point) chipset Boards / Socket G2 (rPGA 988B) [ top ]

Supermicro X9SCV-Q and X9SCV-QV4 motherboards based on the Intel QM67 chipset support Intel's 2nd Generation Core i7/i5/i3, Pentium and Celeron Mobile processors compatible with the socket G2 (rPGA 988B). The compact mini-ITX motherboards are ideal for high-performance, low-power embedded applications, with features that include support for 16GB DDR3 Memory, SATA 3 & SATA 2 HDD/SSD storage with RAID support, Dual Gigabit Ethernet LAN Ports, PCI-E 2.0 x16 slot for added Graphics, Networking or I/O expansion. Additional features include support for Intel's Active Management Technology (vPro 7.0, AMT 7.0) for remote management, security (TPM 1.2) and DC power options.

Product Model Quick View Form Factor Chipset Memory HDD
X9SCV-QV4   C2SBM-Q Mini-ITX Intel QM67 16GB DDR3 2x SATA3
4x SATA2
X9SCV-Q

C2SBM-Q Mini-ITX Intel QM67 16GB DDR3 2x SATA3
4x SATA2




C216 PCH Boards / Socket 1155 [ top ]

Supermicro motherboards based on the Intel C216 PCH chipset with Intel® 2nd and 3rd Generation Core™ i3 processor series and new Generation Intel® Xeon® processor E3-1200 v2 family support in the LGA 1155 socket. With features that include support for PCI-E 3.0, up to 32 GB DDR3 memory, and integrated IPMI 2.0 support (optional), these boards are optimized for Rack and Tower chassis.

Product Model Quick View Form Factor Memory HDD Other Key Features
X9SAE

X9SAE ATX 32 GB DDR3
4 DIMM slots
4x SATA2
2x SATA3
82579LM + 82574L LAN
C216 PCH
X9SAE-V

X9SAE ATX 32 GB DDR3
4 DIMM slots
4x SATA2
2x SATA3
82579LM + 82574L LAN
C216 PCH
X9SPU-F

X9SPU-F Proprietary 32 GB DDR3
4 DIMM slots
4x SATA2
2x SATA3
IPMI 2.0
82574L LAN
C216 PCH




B75/H61 Chipset / Socket H2 (LGA 1155) Boards

Supermicro motherboards based on the Intel 2nd and 3rd Generation Core™ i7/i5/i3 processor series and Intel B75/H61 chipset. With features that include PCI-E 3.0 slot(s), DDR3 memory, LAN port(s), SATA3 ports, multiple USB ports, integrated audio, and TPM header ready, these boards are Supermicro's latest premium desktop motherboards that demonstrate huge leaps in quality, performance, and visual processing capabilities.

Product Model Quick View Form Factor Memory HDD Other Key Features
C7B75   C7B75 Micro ATX 32GB DDR3
4 DIMM slots
1x SATA3
5x SATA2
Audio
1 GbE LAN
Intel B75
C7H61   C7H61 ATX 16GB DDR3
2 DIMM slots
2x SATA3
4x SATA2
Audio
2 GbE LAN
2 USB 3.0
8 COM ports
Intel H61
C7H61-L   C7H61-L ATX 16GB DDR3
2 DIMM slots
2x SATA3
4x SATA2
Audio
2 GbE LAN
Intel H61




Q67 Chipset Boards/ Socket H2 (LGA 1155)

Supermicro motherboards based on the Intel 2nd Generation Core™ processor series and Intel Q67 chipset. With features that include PCI-E 2.0 slot(s), DDR3 memory, dual LAN ports, SATA3 ports with RAID support, multiple USB ports, integrated audio, and TPM header ready, these boards are Supermicro's latest premium desktop motherboards that demonstrate huge leaps in quality, performance, and visual processing capabilities.

Product Model Quick View Form Factor Memory HDD Other Key Features
C7Q67   C7Q67 Micro ATX 32GB DDR3
4 DIMM slots
2x SATA3
4x SATA2
Audio
82579LM LAN
82574L LAN
Intel Q67
C7Q67-H   C7Q67-H ATX 32GB DDR3
4 DIMM slots
2x SATA3
4x SATA2
Audio
82579LM LAN
82574L LAN
Intel Q67




5520 (Tylersburg) Boards / Socket 1366 [ top ]

Supermicro motherboards based on the Intel 5520 chipset support Intel's Xeon® 5500 series processors in the LGA 1366 socket. With features that include support for 36 PCI-E 2.0 lanes, up to 144 GB DDR3 memory, and optional integrated IPMI 2.0 support, these boards deliver the highest performance.

Product Model Quick View Form Factor Memory HDD Other Key Features
X8DTN+-F   X8DTN+-F Enhanced
Ext. ATX
288 GB DDR3
18 DIMM slots
UIO,
6x SATA
IPMI 2.0
Graphics
82576 LAN
X8DTN+   X8DTN+ Enhanced
Ext. ATX
288 GB DDR3
18 DIMM slots
UIO,
6x SATA
Graphics
82576 LAN
3x PCI-X slots
X8DAH+-F   X8DAH+-F Enhanced
Ext. ATX
288 GB DDR3
18 DIMM slots
6x SATA IPMI 2.0
Audio
82576 LAN
X8DAH+   X8DAH+ Enhanced
Ext. ATX
288 GB DDR3
18 DIMM slots
6x SATA Audio
82576 LAN
X8DTH-6F   X8DTH-6F Ext. ATX 192 GB DDR3
12 DIMM slots
8x SAS 2.0 IPMI 2.0
Graphics
82576 LAN
X8DTH-6   X8DTH-6 Ext. ATX 192 GB DDR3
12 DIMM slots
8x SAS 2.0 Graphics
82576 LAN
X8DTH-iF   X8DTH-iF Ext. ATX 192 GB DDR3
12 DIMM slots
6x SATA IPMI 2.0
Graphics
82576 LAN
X8DTH-i   X8DTH-i Ext. ATX 192 GB DDR3
12 DIMM slots
6x SATA Graphics
82576 LAN
X8DTU-F   X8DTU-F Ext. ATX 192 GB DDR3
12 DIMM slots
UIO,
Customizable
IPMI 2.0
Graphics
82576 LAN
X8DTU   X8DTU Ext. ATX 192 GB DDR3
12 DIMM slots
UIO,
Customizable
Graphics
82576 LAN
X8DT3-LN4F   X8DT3-LN4F Ext. ATX 192 GB DDR3
12 DIMM slots
8x SAS IPMI 2.0
82576 LAN (4x ports)
X8DT3-F   X8DT3-F Ext. ATX 192 GB DDR3
12 DIMM slots
8x SAS IPMI 2.0
82576 LAN
X8DT3   X8DT3 Ext. ATX 192 GB DDR3
12 DIMM slots
8x SAS 82576 LAN
X8DTi-LN4F   X8DTi-LN4F Ext. ATX 192 GB DDR3
12 DIMM slots
6x SATA IPMI 2.0
82576 LAN (4x ports)
X8DTi-F   X8DTi-F Ext. ATX 192 GB DDR3
12 DIMM slots
6x SATA IPMI 2.0
82576 LAN
X8DTi   X8DTi Ext. ATX 192 GB DDR3
12 DIMM slots
6x SATA 82576 LAN
X8DA3   X8DA3 Ext. ATX 192 GB DDR3
12 DIMM slots
8x SAS Audio
82573V/L LAN
X8DAi   X8DAi Ext. ATX 192 GB DDR3
12 DIMM slots
6x SATA Audio
IPMI support
82573V/L LAN




3420/3400 (Ibex Peak) Boards / Socket 1156 [ top ]

Supermicro motherboards based on the Intel 3420/3400 Express chipset support Intel's Xeon® X3400/L3400 series processors in the LGA 1156 socket. With features that include support for PCI-E 2.0, up to 32 GB DDR3 memory, and optional integrated IPMI 2.0 support, these boards deliver the highest performance for 1U, 2U+ and pedestal form factors.

Product Model Quick View Form Factor Memory HDD Other Key Features
X8SI6-F   X8SI6-F ATX 32 GB DDR3
6 DIMM slots
8x SAS 2.0 IPMI 2.0
82574L LAN
2x PCI-E slots
X8SIE-LN4F   X8SIE-LN4F ATX 32 GB DDR3
6 DIMM slots
6x SATA,
4x LAN
IPMI 2.0
82574L LAN
(4x ports)
2x PCI-E slots
X8SIE-LN4   X8SIE-LN4 ATX 32 GB DDR3
6 DIMM slots
6x SATA,
4x LAN
82574L LAN
(4x ports)
2x PCI-E slots
X8SIE-F   X8SIE-F ATX 32 GB DDR3
6 DIMM slots
6x SATA IPMI 2.0
82574L LAN
2x PCI-E slots
X8SIE   X8SIE ATX 32 GB DDR3
6 DIMM slots
6x SATA 82574L LAN
2x PCI-E slots
X8SIA-F   X8SIA-F ATX 32 GB DDR3
6 DIMM slots
6x SATA IPMI 2.0
82574L LAN
6x PCI-E slots
X8SIA   X8SIA ATX 32 GB DDR3
6 DIMM slots
6x SATA 82574L LAN
6x PCI-E slots
X8SIL-F   X8SIL-F Micro ATX 32 GB DDR3
6 DIMM slots
6x SATA IPMI 2.0
82574L LAN
3x PCI-E slots
X8SIL-V   X8SIL-F Micro ATX 32 GB DDR3
6 DIMM slots
6x SATA 82574L LAN
3x PCI-E slots
X8SIL
Intel 3400 (Ibex Peak)
X8SIL-F Micro ATX 32 GB DDR3
6 DIMM slots
4x SATA 82574L LAN
3x PCI-E slots
3400 Chipet
X8SIU-F   X7SBU-F Proprietary 32 GB DDR3
6 DIMM slots
UIO,
Customizable
IPMI 2.0
82574L LAN
4x PCI-E slots
X8SIT-HF   X7SBT Proprietary 32 GB DDR3
6 DIMM slots
6x SATA IPMI 2.0
82576BE LAN
1x PCI-E slot
X8SIT-F   X7SBT Proprietary 32 GB DDR3
6 DIMM slots
6x SATA IPMI 2.0
82574L LAN
1x PCI-E slot



Q57 (Ibex Peak) Boards / Socket 1156 [ top ]

Supermicro motherboards based on the Intel Q57 chipset support Intel's Core™ i7 / i5 / i3 / Pentium® processors. Supermicro's Q57 boards are designed for embedded applications that require long life and continuous operation in high-temperature environments.

Product Model Quick View Form Factor Memory HDD Other Key Features
C7SIM-Q   C2SBM-Q Micro ATX 16 GB DDR3
4 DIMM slots
6x SATA Audio
82578DM LAN
82574L LAN




3210 (Bigby-P) Boards / Socket 775 [ top ]

Supermicro's 3210 chipset-based motherboards support Intel Xeon® 3300/3200/3100/3000 series processors and the next generation 45 nm processors. With support for a 1333 MHz system bus and up to 8GB 800/667 MHz DDR II memory, these products are ideal for entry-level server platforms and cost-effective HPC clusters.

Product Model Quick View Form Factor Chipset Memory HDD
X7SB3-F   X7SB3-F ATX Intel 3210
(Bigby-P)
8 GB DDR2 8x SAS,
2x SATA
X7SB3   X7SB3 ATX Intel 3210
(Bigby-P)
8 GB DDR2 8x SAS,
2x SATA
X7SB4   X7SB4 ATX Intel 3210
(Bigby-P)
8 GB DDR2 U320 SCSI,
6x SATA
X7SBE   X7SBE ATX Intel 3210
(Bigby-P)
8 GB DDR2 6x SATA
X7SBA   X7SBA ATX Intel 3210
(Bigby-P)
8 GB DDR2 6x SATA
X7SBi   X7SBi ATX Intel 3210
(Bigby-P)
8 GB DDR2 6x SATA



3010 (Mukilteo 2P) Boards / Socket 775 [ top ]

Supermicro's 3010 chipset motherboards support Intel Xeon® 3200/3000 Series processors, Core™2 Duo, Pentium® D, Pentium® 4 Extreme Edition (64-bit), Pentium® 4, and Celeron® D processors. These products are well-suited for entry-level server platforms and cost-effective HPC clusters for high performance personal super-computing.

Product Model Quick View Form Factor Chipset Memory HDD
PDSMA-E+   PDSMA-E+ ATX Intel 3010
(Mukilteo-2P)
8 GB DDR2 4x SATA
PDSM4+   PDSM4+ ATX Intel 3010
(Mukilteo-2P)
8 GB DDR2 U320 SCSI,
4x SATA
PDSME+   PDSME+ ATX Intel 3010
(Mukilteo-2P)
8 GB DDR2 4x SATA
PDSML-E+   PDSML-E+ Micro ATX Intel 3010
(Mukilteo-2P)
8 GB DDR2 4x SATA
PDSMU   PDSMU Proprietary Intel 3010
(Mukilteo-2P)
8 GB DDR2 Customizable



Q35 (Bearlake Q) Boards / Socket 775 [ top ]

Supermicro motherboards based on the Intel Q35 chipset support Intel's Core™ 2 Extreme / Quad / Duo processors. Supermicro's Q35 boards are designed for embedded applications that require long life and continuous operation in high-temperature environments.

Product Model Quick View Form Factor Chipset Memory HDD
C2SBC-Q   C2SBC-Q ATX Intel Q35
(Bearlake Q)
8 GB DDR2 6x SATA
C2SBM-Q   C2SBM-Q Micro ATX Intel Q35
(Bearlake Q)
8 GB DDR2 4x SATA



G45 / G41 (Eaglelake) Boards / Socket 775 [ top ]

Supermicro motherboards based on the Intel G45 / G41 chipset support Intel's Core™ 2 Extreme / Quad / Duo series processors. With features that include 1 PCI-E 2.0 x16 slot and DDR3 memory support, these boards deliver leading performance for home computing and entertainment applications.

Product Model Quick View Form Factor Chipset Memory HDD
C2SEA   C2SEA ATX Intel G45
(Eaglelake)
8 GB DDR3 6x SATA
C2G41   C2G41 Micro ATX Intel G41
(Eaglelake)
4 GB DDR3 4x SATA



Q965 (Broadwater) Boards / Socket 775 [ top ]

Q965 chipset motherboards support Intel's new Core™ 2 Quad / Duo, Pentium® D, Pentium® 4 and Celeron® D processors. These boards deliver innovative capabilities and usages for both Small and Medium/Large businesses.

Product Model Quick View Form Factor Chipset Memory HDD
PDSBA-Q+   PDSBA-Q+ ATX Intel Q965
(Broadwater)
8 GB DDR2 4x SATA



945GC Boards / Socket 775 [ top ]

The 945GC chipset motherboards are well-suited for entry-level server platforms, cost-effective HPC clusters, and server appliances.

Product Model Quick View Form Factor Chipset Memory HDD
X7SLM-L   X7SLM-L uATX Intel 945GC
2 GB DDR2 4x SATA
X7SLM+   X7SLM+ uATX Intel 945GC
2 GB DDR2 4x SATA
X7SLM   X7SLM uATX Intel 945GC
2 GB DDR2 4x SATA



945G Boards / Socket 775 [ top ]

The 945G chipset motherboards support Dual-core Intel CPU's including Pentium® D processors and Pentium® Extreme Edition processors. Also supported are Pentium® 4 (including Extreme Edition) as well as Celeron® D processors. These products deliver superb performance through 1066MHz system bus, PCI-Express (x16) interface and SATA high-speed storage.

Product Model Form Factor Chipset Memory HDD
PDSLA ATX Intel 945G
(Lakeport-G)
4GB DDR2 4x SATA




5100 (San Clemente) Boards / Socket 771 [ top ]

Supermicro's 5100 chipset-based serverboard products support the next-generation quad-core Xeon® 5400/5300 and dual-core Xeon® 5200/5100 processors. With up to 48GB DDR II native registered, ECC memory and increased PCI-Express slot capability, these Supermicro server boards are available in various optimized models.

Product Model Quick View Form Factor Chipset Memory HDD
X7DCU   X7DWU Ext. ATX Intel 5100
(San Clemente)
48 GB DDR2 DIMM UIO,
Customizable
X7DCA-3   X7DCA-3 Ext. ATX Intel 5100
(San Clemente)
48 GB DDR2 DIMM 8x SAS,
6x SATA
X7DCA-i   X7DCA-i Ext. ATX Intel 5100
(San Clemente)
48 GB DDR2 DIMM 6x SATA
X7DCX   X7DCX Ext. ATX Intel 5100
(San Clemente)
48 GB DDR2 DIMM 6x SATA
X7DCL-3   X7DCL-3 ATX Intel 5100
(San Clemente)
48 GB DDR2 DIMM 8x SAS,
6x SATA
X7DCL-i   X7DCL-i ATX Intel 5100
(San Clemente)
48 GB DDR2 DIMM 6x SATA
X7DCA-L   X7DCA-L ATX Intel 5100
(San Clemente)
48 GB DDR2 DIMM 6x SATA
X7DCT-3IBXF*   X7DCT-3IBXF Proprietary Intel 5100
(San Clemente)
48 GB DDR2 DIMM 4x SAS
X7DCT-3F   X7DCT-3F Proprietary Intel 5100
(San Clemente)
48 GB DDR2 DIMM 4x SAS
X7DCT-3   X7DCT-3 Proprietary Intel 5100
(San Clemente)
48 GB DDR2 DIMM 4x SAS
X7DCT-LF   X7DCT-LF Proprietary Intel 5100
(San Clemente)
48 GB DDR2 DIMM 4x SATA
X7DCT-L   X7DCT-L Proprietary Intel 5100
(San Clemente)
48 GB DDR2 DIMM 4x SATA
X7DCT-10G   X7DCT-10G Proprietary Intel 5100
(San Clemente)
48 GB DDR2 DIMM 4x SATA
X7DCT   X7DCT Proprietary Intel 5100
(San Clemente)
48 GB DDR2 DIMM 4x SATA



5000P (Blackford) Boards / Socket 771 [ top ]

Supermicro's 5000P chipset-based serverboard products support the next-generation quad-core Xeon® 5400/5300 and dual-core Xeon® 5200/5100 processors. With up to 64GB FB-DIMM memory and increased PCI-Express slot capability, these Supermicro server boards are available in various optimized models.

Product Model Quick View Form Factor Chipset Memory HDD
X7DB8+   X7DB8+ Enhanced
Ext. ATX
Intel 5000P
(Blackford)
64 GB FB-DIMM Dual U320,
6x SATA, ZCR
X7DBE+   X7DBE+ Enhanced
Ext. ATX
Intel 5000P
(Blackford)
64 GB FB-DIMM 6x SATA
X7DBi+   X7DBi+ Enhanced
Ext. ATX
Intel 5000P
(Blackford)
64 GB FB-DIMM 6x SATA
X7DBT-INF   X7DBT-INF Ext. ATX Intel 5000P
(Blackford)
32 GB FB-DIMM 4x SATA
X7DBT   X7DBT Proprietary Intel 5000P
(Blackford)
32 GB FB-DIMM 4x SATA
X7DB8-X   X7DB8-X Ext. ATX Intel 5000P
(Blackford)
32 GB FB-DIMM Dual U320,
6x SATA, ZCR
X7DBE-X   X7DBE-X Ext. ATX Intel 5000P
(Blackford)
32 GB FB-DIMM 6x SATA
X7DBU   X7DBU Ext. ATX Intel 5000P
(Blackford)
32 GB FB-DIMM Customizable
X7DBN   X7DBN Ext. ATX Intel 5000P
(Blackford)
32 GB FB-DIMM Customizable
X7DB3   X7DB3 Ext. ATX Intel 5000P
(Blackford)
32 GB FB-DIMM 8x SAS,
6x SATA, ZCR
X7DB8   X7DB8 Ext. ATX Intel 5000P
(Blackford)
32 GB FB-DIMM Dual U320,
6x SATA, ZCR
X7DBE   X7DBE Ext. ATX Intel 5000P
(Blackford)
32 GB FB-DIMM 6x SATA
X7DBR-8+ *   X7DBR-8+ 1U Enhanced
Ext. ATX
Intel 5000P
(Blackford)
64 GB FB-DIMM Dual 320,
6x SATA, ZCR
X7DBR-i+ *   X7DBR-i+ 1U Enhanced
Ext. ATX
Intel 5000P
(Blackford)
64 GB FB-DIMM 6x SATA
X7DBR-3 *   X7DBR-3 1U Ext. ATX Intel 5000P
(Blackford)
32 GB FB-DIMM 8x SAS,
6x SATA, ZCR
X7DBR-E *   X7DBR-E 1U Ext. ATX Intel 5000P
(Blackford)
32 GB FB-DIMM 6x SATA
X7DBR-8 *   X7DBR-3 1U Ext. ATX Intel 5000P
(Blackford)
32 GB FB-DIMM Dual U320,
6x SATA, ZCR
X7DBR-i *   X7DBR-3 1U Ext. ATX Intel 5000P
(Blackford)
32 GB FB-DIMM 6x SATA
X7DBX-8 *   X7DBX-8 Proprietary
1U
Intel 5000P
(Blackford)
32 GB FB-DIMM Dual U320,
6x SATA, ZCR
X7DBX-i *   X7DBX-i Proprietary
1U
Intel 5000P
(Blackford)
32 GB FB-DIMM 6x SATA
X7DBP-8 *   X7DBP-8 Proprietary
1U
Intel 5000P
(Blackford)
32 GB FB-DIMM Dual U320,
6x SATA, ZCR
X7DBP-i *   X7DBP-i Proprietary
1U
Intel 5000P
(Blackford)
32 GB FB-DIMM 6x SATA




945GME Boards / Socket 478 [ top ]

The 945GME chipset motherboards support the Intel's Core™ 2 Duo mobile series, as well as Core™ Duo LV / ULV, Core™ Solo ULV and Celeron M processors. These products are well-suited for long life and continuous operation in high-temperature environments.

Product Model Quick View Form Factor Chipset Memory HDD
PDSLM *   PDSLM Mini ITX Intel 945GME
4 GB DDR2 2x SATA

  * = For OEMs Only

Product Highlights

X9SCV-QV4
X9SCV-QV4
Intel® 2nd Gen. Core i7/i5/i3 (rPGA 988B), Intel QM67 Chipset, up to 16GB DDR3, 2x GbE ports, 4x SATA2, 2x SATA3, 2x HDMI, HD Audio, DOM Power connector, PCI-E x16 Slot and 11 USB Ports.
X9SPV-F-3217UE
X9SPV-F-3217UE
Intel® Core i3-3217UE, 17W, 16GB DDR3, 2 GbE LAN, 6 SATA, 1 PCIex16 slot and IPMI 2.0 with KVM
X9DRL-EF
X9DRL-EF
Dual Intel® Xeon® E5-2600, C602J chipset. 2 GbE LAN ports, 4 PCI-E slots, 7 USB ports, 4 SATA2 ports, 2 SATA3 ports, and Integrated Graphics
X9DRX+-F
X9DRX+-F
Dual Intel® Xeon® E5-2600, C602 chipset. 2 GbE LAN ports, 11 PCI-E slots, 10 USB ports, 8 SATA2 ports, 2 SATA3 ports, and Integrated Graphics
C7Q67
C7Q67
Intel® Core™ i3/i5/i7. Q67 chipset. Up to 32GB DDR3, 2 GbE LAN Ports, 4 SATA 3.0, 4 SATA 2.0, 5 PCI-E 2.0 Slots
Terms & Conditions   |   Privacy   |   Investor Relations   |   Jobs   |   Site Map
SuperServer® | Motherboards | Chassis | SuperRack® | SuperBlade® | Embedded | Networking | Storage | Accessories | AMD Solutions | Power Supplies

Copyright © 2014 Super Micro Computer, Inc. Information in this document is subject to change without notice.
Other products and companies referred to herein are trademarks or registered trademarks of their respective companies or mark holders.
