Memory Menu
MemSS Max OC Ratio Limit
This feature shows the maximum overclocking ratio limit for the memory subsystem.
MemSS Max OC Ratio
Enter a value to set the maximum overclocking ratio for the memory subsystem. The default is 0.
VF Offset Mode
Use this feature to set VF Offset mode. In Legacy mode, it sets a global offset for the entire VF curve. In Selection mode, it sets a selected VF point. Reboot the system after enabling overclocking feature to initialize the default value. The options are Legacy and Selection.
Note: The following features are available when "VF Offset Mode" is set to Legacy.
MemSS Voltage Mode
Use this feature to select the memory subsystem voltage mode. In adaptive mode, the voltage is interpolated only in turbo mode. In override mode, the voltage selected will be applied over all operating frequencies. The options are Adaptive and Override.
MemSS Adaptive Voltage (Available when “MemSS Voltage Mode” is set to Adaptive)
Use this feature to specify the adaptive voltage (in mV) applied while memory subsystem is operating in adaptive mode. The range is 0–2000 and the default is 0.
MemSS Voltage Override (Available when “MemSS Voltage Mode” is set to Override)
Use this feature to specify the override voltage (in mV) applied while memory subsystem is operating in override mode. The range is 0–2000 and the default is 0.
MemSS Voltage Offset
Enter a value for the offset voltage (in mV) that will be applied to the memory subsystem domain. The range is - 500 to 500 and the default is 0.
Offset Prefix
Use this feature to set the prefix value as a positive (+) or a negative (-). The options are “+” and “-”.
Note: The following VF Point features are only available when VF Offset Mode is set to Selection. The number of VF point depends on the CPU and the domain.
VF Point # Offset
Enter a value to specify the offset voltage (in mV) that will be applied to the VF point #. The range is -500 to 500. The default is 0.
VF Point # Offset Prefix
Use this feature to set the prefix value as a positive (+) or a negative (-). The options are “+” and “-”.
VF Point # Ratio
This feature shows the VF point # ratio.
