NIC1/NIC2 (LAN1/LAN2)
The Network Interface Controller (NIC) LED connection for LAN port 1 is located on pins 11 and 12 of JF1 on the X14SAZ-TLN4F motherboard, and LAN port 2 is on pins 9 and 10. Attach the NIC LED cables here to display network activity.
For a detailed diagram of the X14SAZ-TLN4F motherboard, see the layout under Motherboard Quick Reference.
|
LAN1/LAN2 LED Pin Definitions (JF1) |
|
|---|---|
|
Pin# |
Definition |
|
9 |
3.3 V Stby |
|
10 |
NIC2 Link/Active LED |
|
11 |
3.3 V Stby |
|
12 |
NIC1 Link/Active LED |
