I/O Connections

Front I/O Module Header

An Supermicro proprietary front I/O module header is located at JFP2 on the X14DBG-GD motherboard. This header can be connected to the front I/O module (AOM-DXF-IO-P) via a cable. The AOM-DXF-IO-P provides connections of one dedicated BMC LAN port, two USB 3.0 ports, one VGA port, and one COM header.

For a detailed diagram of the X14DBG-GD motherboard, see the layout under Motherboard Quick Reference.
