2U Twin^2 Solutions Supermicro FatTwin Server Solutions



Titanium Level 96% Efficiency
FatTwin™ Server Solution - Best TCO with Highest Performance-per-Watt/per-Dollar

The new generation X11 Supermicro FatTwin™ is a high-density 8/4 hot-plug node SuperServer® system available with a variety of memory capacities, HDD technologies, M.2 SSD NVMe, PCIe alternatives, and networking capabilities. The FatTwin™ supports up to: 1.5TB ECC RDIMM DDR4-2666MHz memory in 12 DIMM slots, 1 PCI-E 3.0 x16 and 1 SIOM flexible nework card 8 ports of Broadcom SAS 3.0 (12Gbps) HBA or HW RAID, 10 ports of SATA 3.0 (6Gbps) with Intel® C621 controller, redundant Titanium Level (96%) Digital power supplies, integrated IPMI 2.0 with KVM over dedicated LAN, and dual Intel® Xeon® Scalable processor families up to 26 cores and 165W TDP.

The Supermicro FatTwin™ represents a revolution in Green Computing and is highly efficient by design; this system supports customers' critical applications while reducing Data Center TCO in order to help preserve the environment, and extends the compute and storage capabilities of Supermicro's existing Twin SuperServer® systems to achieve increased performance and power efficiency. Due to its shared components, the FatTwin™ improves cost-effectiveness and reliability, while its modular architecture makes it flexible to configure and easy to maintain.

Versatile configurations allow the FatTwin™ to be optimized for many different environments including Enterprise, Data Center, Cloud Computing, HPC, Financial, Science and Engineering, File and Storage Servers.

  • NEW! Support for New Generation X11 Solutions with Dual Intel® Xeon® Scalable processor up to 165W per node
  • 12 DIMM slots; Up to 1.5TB ECC RDIMM
  • Low-Profile PCI-E 3.0 x16 slot
  • SAS3/SATA3/NVMe support
  • Redundant 2200W/1200W Titanium (96%) Power Supplies





X10 X11

  Solution Families -
Application / Product Families: | Display All | GPGPU | Hadoop/Storage | NVMe Ready |
Display by Features: | Front / Rear I/O | 2.5" / 3.5" | 4 / 8 Node | 29" / 35" Enclosure |



F619P2 Front
SYS-F619P2-RT / F619P2-RTN / F619P2-RC0 / F619P2-RC1 (8 DP Nodes with Rear I/O)

• FatTwin™ Server; EACH NODE (x8 Hot-plug System Nodes):
• Dual Socket P (LGA 3647) support: Intel® Xeon® Scalable processor; dual UPI up to 10.4GT/s
• 12 DIMM slots; up to 1.5TB ECC 3DS LRDIMM, up to DDR4-2666MHz
• Storage Options (all Hot-swap):
     F619P2-RT - 6 2.5" SATA3
     F619P2-RTN - 6 2.5" SATA3 or 2 SATA3 + 4 NVMe U.2
     F619P2-RC0 - 6 2.5" SAS3 or 2 SAS3 + 4 opt. NVMe U.2; SAS3 with Broadcom 3008
     F619P2-RC1 - 6 2.5" SAS3 or 2 SAS3 + 4 opt. NVMe U.2; SAS3 with Broadcom 3108
• 1 PCI-E 3.0 x16 (LP), 1 PCI-E 3.0 x16 (SIOM)
Titanium Level • SIOM flexible Network card, 1 Dedicated IPMI port
• 1 VGA, 2 USB 3.0, 1 M.2 support
• 3x 4cm 20k RPM middle fans
• 2200W Redundant Titanium Level (96%) Power Supplies



F629P3 Front
SYS-F629P3-RTB / F629P3-RTBN / F629P3-RC0B / F629P3-RC1B (4 DP Nodes with Rear I/O)

• FatTwin™ Server; EACH NODE (x4 Hot-plug System Nodes):
• Dual Socket P (LGA 3647) support: Intel® Xeon® Scalable processor; dual UPI up to 10.4GT/s
• 12 DIMM slots; up to 1.5TB ECC 3DS LRDIMM, up to DDR4-2666MHz
• Storage Options (all Hot-swap):
     F629P3-RTB - 8 3.5" SATA3
     F629P3-RTBN - 8 3.5" SATA3 or 6 SATA3 + 2 NVMe U.2
     F629P3-RC0B - 8 3.5" SAS3 or 6 SAS3 + 2 opt. NVMe U.2; SAS3 with Broadcom 3008
     F629P3-RC1B - 8 3.5" SAS3 or 6 SAS3 + 2 opt. NVMe U.2; SAS3 with Broadcom 3108
• 1 PCI-E 3.0 x16 (LP), 1 PCI-E 3.0 x16 (SIOM)
Titanium Level • SIOM flexible Network card, 1 Dedicated IPMI port
• 1 VGA, 2 USB 3.0, 1 M.2 support
• 2x 8cm 14k RPM middle fans
• 1200W Redundant Titanium Level (96%) Power Supplies



F628R3 Front
SYS-F628R3-RTBN+ / SYS-F628R3-RTBPTN+ (4 DP Nodes with Rear I/O)

• FatTwin™ Server; EACH NODE (x4 Hot-plug System Nodes):
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family
• 8 Hot-swap 3.5" Drive Bays per U: 8x SATA3 or 6x SATA3 + 2x NVMe
• 16 DIMM slots; up to 2TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
• 1 PCI-E 3.0 x16, 1x PCI-E 3.0 x8 Micro LP slot (flexible networking opt.)
• Ports: 2 GbE/10GBase-T ("PT"), 1x Video, 2x USB 3.0
Platinum Level • System management: Built-in Server management tool
   (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
• 2x 8cm 11K RPM middle fans
• 1280W Redundant Platinum Level Power Supplies



F628R3 Front
SYS-F628R3-RC1B+ / SYS-F628R3-RC1BPT+ / SYS-F628R3-RC0B+ / SYS-F628R3-RC0BPT+
(4 DP Nodes with Rear I/O)

• FatTwin™ Server; EACH NODE (x4 Hot-plug System Nodes):
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family
• 8 Hot-swap 3.5" drive bays: 8 SAS3 or 6 SAS3 + 2 NVMe SSD
   SAS3 (12Gbps) support via Broadcom 3108 ("C1") / Broadcom 3008 ("C0")
• 16 DIMM slots; up to 2TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
• 1 PCI-E 3.0 x16, 1 PCI-E 3.0 x8 Micro LP slot (flexible networking opt.)
• Ports: 2 GbE/10GBase-T ("PT+"), 1 Video, 2 USB 3.0
Platinum Level • System management: Built-in Server management tool
   (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
• 2 heavy duty internal fans, optional rear fan w/ Optimal Fan Speed Control
• 1280W Redundant Platinum Level Power Supplies



F627R3 Front
SYS-F628R3-RTB+ / SYS-F628R3-R72B+ / SYS-F628R3-RTBPT+ / SYS-F628R3-R72BPT+
(4 DP Nodes with Rear I/O)

• FatTwin™ Server; EACH NODE (x4 Hot-plug System Nodes):
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family
• 6 + 2 Hot-swap 3.5" SATA3 HDD Bays(-RTB+ and -RTBPT+ SKUs);
   SAS2 support via Broadcom 2208 (-R72B+ and -R72BPT+ SKUs)
• 16 DIMM slots; up to 2TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
• 1 PCI-E 3.0 x16, 1 PCI-E 3.0 x8 Micro LP slot (flexible networking opt.)
• Ports: 2 GbE/10GBase-T ("PT+"), 1 Video, 2 USB 3.0
Platinum Level • System management: Built-in Server management tool
   (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
• 2x 8cm 11K RPM middle fans
• 1280W Redundant Platinum Level Power Supplies



F618R2 Front
SYS-F618R2-RTN+ / SYS-F618R2-RTPTN+ (8 DP Nodes with Rear I/O)

• FatTwin™ Server; EACH NODE (x8 Hot-plug System Nodes):
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family
• 6 Hot-swap 2.5" drive bays: 6 SATA3 or 4 SATA3 + 2 NVMe SSD
• 16 DIMM slots; up to 2TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
• 1 PCI-E 3.0 x16, 1 PCI-E 3.0 x8 Micro LP slot (flexible networking opt.)
• Ports: 2 GbE/10GBase-T ("PT+"), 1 Video, 2 USB 3.0
TItaninum Level • System management: Built-in Server management tool
   (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
• 3 heavy duty internal fans, optional rear fan w/ Optimal Fan Speed Control
• 2000W Redundant Titanium Level (96%) High-efficiency Digital Power Supplies



F618R2 Front
SYS-F618R2-RC1+ / SYS-F618R2-RC1PT+ / SYS-F618R2-RC0+ / SYS-F618R2-RC0PT+
(8 DP Nodes with Rear I/O)

• FatTwin™ Server; EACH NODE (x8 Hot-plug System Nodes):
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family
• 6 Hot-swap 2.5" drive bays: 6 SAS3 or 4 SAS3 + 2 NVMe SSD
   SAS3 support via Broadcom 3108 ("C1") / Broadcom 3008 ("C0")
• 16 DIMM slots; up to 2TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
• 1 PCI-E 3.0 x16, 1 PCI-E 3.0 x8 Micro LP slot (flexible networking opt.)
• Ports: 2 GbE/10GBase-T ("PT+"), 1 Video, 2 USB 3.0
TItaninum Level • System management: Built-in Server management tool
   (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
• 3 heavy duty internal fans, optional rear fan w/ Optimal Fan Speed Control
• 2000W Redundant Titanium Level (96%) High-efficiency Digital Power Supplies



F618R2 Front
SYS-F618R2-RT+ / SYS-F618R2-R72+ / SYS-F618R2-RTPT+ / SYS-F618R2-R72PT+
(8 DP Nodes with Rear I/O)

Key Features
• FatTwin™ Server; EACH NODE (x8 Hot-plug System Nodes):
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family
• 6 Hot-swap 2.5" SATA3 HDD Bays (-RT+ and -RTPT+ SKUs);
   SAS2 support via Broadcom 2208 (-R72+ and -R72PT+ SKUs)
• 16 DIMM slots; up to 2TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
• 1 PCI-E 3.0 x16, 1 PCI-E 3.0 x8 Micro LP slot (flexible networking opt.)
• Ports: 2 GbE/10GBase-T ("PT+"), 1 Video, 2 USB 3.0
Platinum Level • System management: Built-in Server management tool
   (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
• 3x 4cm 14K RPM middle fans
• 1620W Redundant Platinum Level Power Supplies



F618H6-FT(PT)+ Front SYS-F618H6-FTPT+ / SYS-F618H6-FT+ (Hadoop, 4 DP Nodes with Front I/O)

Key Features
• Up to 8 Fixed 3.5" SAS3/SATA3 + 4 Fixed 3.5" SATA3 HDDs per U
• Evolutionary 4U Twin Architecture that Offers Industry's Best Capacity and Efficiency
• 4 Hot-plug System Nodes in 4U
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family
• 16 DIMM slots; up to 2TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
• 2 PCI-E 3.0 x8 (LP) expansion slots via riser card
• Ports: 2 GbE/10GBase-T ("PT"), 1 Video, 2 USB 3.0
TItaninum Level • Server Management with Onboard IPMI 2.0 through Dedicated LAN Port
• SAS3 (12Gbps) via Broadcom 3008 controller; SW RAID 0, 1, 10 support
• 8x 8cm heavy duty fans with PWM fan speed control
• 2000W Redundant Titanium Level (96%) High-efficiency Digital Power Supplies



F618H6-FT(PT)L+ Front SYS-F618H6-FTPTL+ / SYS-F618H6-FTL+ (Hadoop, 4 DP Nodes with Front I/O)

Key Features
• Up to 8 Fixed 3.5" SAS/SATA + 4 Fixed 3.5" SATA HDDs per U
• Evolutionary 4U Twin Architecture that Offers Industry's Best Capacity and Efficiency
• 4 Hot-plug System Nodes in 4U
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family
• 16 DIMM slots; up to 2TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
• 2 PCI-E 3.0 x8 (LP) expansion slots via riser card
• Ports: 2 GbE/10GBase-T ("PT"), 1 Video, 2 USB 3.0
TItaninum Level • Server Management with Onboard IPMI 2.0 through Dedicated LAN Port
• SAS3 (12Gbps) via Broadcom 3008 controller; SW RAID 0, 1, 10 support
• 8x 8cm heavy duty fans with PWM fan speed control
• 2000W Redundant Titanium Level (96%) High-efficiency Digital Power Supplies



F628G3-F Front
SYS-F628R3-FT+ / SYS-F628R3-FTPT+ / SYS-F628R3-FC0+ / SYS-F628R3-FC0PT+
(4 DP Nodes with Front I/O)

Key Features
• Up to 2 Hot-swap 3.5" SATA (-FT+/-FTPT+) or SAS3 (-FC0+/-FC0PT+) HDDs per U
• Outstanding high-density compute performance for Engineering and Scientific Research,
   Modeling, Simulation and HPC applications
• 4 Hot-plug System Nodes in 4U
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family
• 16 DIMM slots; up to 2TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
• 2 PCI-E 3.0 x8 (FH HL) slots
• Ports: 2 GbE/10GBase-T ("PT"), 1 Video, 2 USB 3.0
Platinum Level • Server Management with Onboard IPMI 2.0 through Dedicated LAN Port
• SAS3 (12Gbps) via Broadcom 3008 controller ("C0"); SW RAID 0, 1 support
• 8x 8cm heavy duty 9.5K hot swappable fans with air shroud and PWM fan speed control
• 1280W Redundant Platinum Level Power Supplies



F628G2-F Front
SYS-F628R2-FT+ / SYS-F628R2-FTPT+ / SYS-F628R2-FC0+ / SYS-F628R2-FC0PT+
(4 DP Nodes with Front I/O)

Key Features
• Up to 6 Hot-swap 2.5" SATA3 (-FT+/-FTPT+) or SAS3 (-FC0+/-FC0PT+) HDDs per U
• Outstanding high-density compute performance for Engineering and Scientific Research,
   Modeling, Simulation and HPC applications
• 4 Hot-plug System Nodes in 4U
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family
• 16 DIMM slots; up to 2TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
• 2 PCI-E 3.0 x8 (FH HL) slots
• Ports: 2 GbE/10GBase-T ("PT"), 1 Video, 2 USB 3.0
Platinum Level • Server Management with Onboard IPMI 2.0 through Dedicated LAN Port
• SAS3 (12Gbps) via Broadcom 3008 controller ("C0"); SW RAID 0, 1, 10 support
• 8x 8cm heavy duty 9.5K hot swappable fans with air shroud and PWM fan speed control
• 1280W Redundant Platinum Level Power Supplies



F628G3-F Front
SYS-F628G3-FT+ / SYS-F628G3-FTPT+ / SYS-F628G3-FC0+ / SYS-F628G3-FC0PT+
(12 GPU/Coprocessor MIC, Front I/O)

Key Features
• Up to 2 Hot-swap 3.5" SATA (-FT+/-FTPT+) or SAS3 (-FC0+/-FC0PT+) HDDs per U
• Outstanding high-density compute performance for Engineering and Scientific Research,
   Modeling, Simulation and HPC applications
• 4 Hot-plug System Nodes in 4U
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family
• 16 DIMM slots; up to 2TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
• 3 PCI-E 3.0 x16 support 3 Double-width GPU/MIC; and 2 PCI-E 3.0 x8 Low-profile slots
• Ports: 2 GbE/10GBase-T ("PT"), 1 Video, 2 USB 3.0
TItaninum Level • Server Management with Onboard IPMI 2.0 through Dedicated LAN Port
• SAS3 (12Gbps) via Broadcom 3008 controller ("C0"); SW RAID 0, 1 support
• 8x 8cm heavy duty 11K fans with air shroud and PWM fan speed control
• 2000W Redundant Titanium Level (96%) High-efficiency Digital Power Supplies



F628G2-F Front
SYS-F628G2-FT+ / SYS-F628G2-FTPT+ / SYS-F628G2-FC0+ / SYS-F628G2-FC0PT+
(12 GPU/Coprocessor MIC, Front I/O)

Key Features
• Up to 6 Hot-swap 2.5" SATA (-FT+/-FTPT+) or SAS3 (-FC0+/-FC0PT+) HDDs per U
• Outstanding high-density compute performance for Engineering and Scientific Research,
   Modeling, Simulation and HPC applications
• 4 Hot-plug System Nodes in 4U
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family
• 16 DIMM slots; up to 2TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
• 3 PCI-E 3.0 x16 support 3 Double-width GPU/MIC; and 2 PCI-E 3.0 x8 Low-profile slots
• Ports: 2 GbE/10GBase-T ("PT"), 1 Video, 2 USB 3.0
TItaninum Level • Server Management with Onboard IPMI 2.0 through Dedicated LAN Port
• SAS3 (12Gbps) via Broadcom 3008 controller ("C0"); SW RAID 0, 1, 10 support
• 8x 8cm heavy duty 11K fans with air shroud and PWM fan speed control
• 2000W Redundant Titanium Level (96%) High-efficiency Digital Power Supplies



F618R2-F Front
SYS-F618R2-FT+ / SYS-F618R2-FTPT+ / SYS-F618R3-FT+ / SYS-F618R3-FTPT+
(8 DP Nodes with Front I/O)

Key Features
• FatTwin™ Server; EACH NODE (x8 Hot-plug System Nodes):
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family
• 4 Fixed 2.5" ("R2") or 2 Fixed 3.5" ("R3") SATA3 drive bays
• 16 DIMM slots; up to 2TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
• 1 PCI-E 3.0 x8 and 1 PCI-E 2.0 x4 or 2 PCI-E 3.0 x8 (optional)
• Ports: 2 GbE/10GBase-T ("PT+"), 1 Video, 2 USB 3.0
TItaninum Level • System management: Built-in Server management tool
   (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
• 8x 8cm 9.5k RPM Rear fans
• 2000W Redundant Titanium Level (96%) High-efficiency Digital Power Supplies



F617R2-F Front
SYS-F618R2-FT / SYS-F618R2-FC0 (8 DP Nodes with Front I/O)

Key Features
• FatTwin™ Server; EACH NODE (x8 Hot-plug System Nodes):
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family
• 2x 2.5" Hot-swap SATA3 HDD Bays (F618R2-FT);
   2x 2.5" Hot-swap SAS3 HDD Bays; SAS3 via Broadcom 3008 (F618R2-FC0)
• 8x DIMM slots; up to 1TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
• 1x PCI-E 3.0 x16 Low-profile slot
• I/O ports: 2x GbE, 1x Video, 2x USB 3.0
Platinum Level • System management: Built-in Server management tool
   (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
• 8x 8cm 9.5K RPM Rear fans total in the system
• 1620W Redundant Platinum Level Power Supplies



F617R2 Front
SYS-F618R3-FT (8 DP Nodes with Front I/O)

Key Features
• FatTwin™ Server; EACH NODE (x8 Hot-plug System Nodes):
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family
• 2 Fixed 3.5" SATA3 HDD Bays
• 8 DIMM slots; up to 1TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
• 1 PCI-E 3.0 x16 Low-profile slot
• Ports: 2 GbE, 1 Video, 2 USB 3.0
Platinum Level • System management: Built-in Server management tool
   (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
• 8x 8cm 9.5K RPM Rear fans total in the system
• 1620W Redundant Platinum Level Power Supplies



F617R2 Front
SYS-F618R3-FTL (8 DP Nodes with Front I/O)

Key Features
• FatTwin™ Server; EACH NODE (x8 Hot-plug System Nodes):
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family
• 2 Fixed 3.5" SATA3 HDD Bays
• 8 DIMM slots; up to 1TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
• 1 PCI-E 3.0 x16 Low-profile slot
• Ports: 2 GbE, 1 Video, 2 USB 3.0
Platinum Level • System management: Built-in Server management tool
   (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
• 2x 17cm Rear fans total in the system
• 1620W Redundant Platinum Level Power Supplies



F627R3 Front
SYS-F628R3-FT / SYS-F628R3-FC0 (4 DP Nodes with Front I/O)

Key Features
• FatTwin™ Server; EACH NODE (x4 Hot-plug System Nodes):
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family
• 4 Hot-swap 3.5" SATA3 HDD Bays (F628R3-FT);
   4 Hot-swap 3.5" SAS3 HDD Bays; SAS3 via Broadcom 3008 (F628R3-FC0)
• 8 DIMM slots; up to 1TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
• 1 PCI-E 3.0 x16 Low-profile slot
• Ports: 2 GbE, 1 Video, 2 USB 3.0
Platinum Level • System management: Built-in Server management tool
   (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
• 8x 8cm 9.5K RPM Rear fans total in the system
• 1280W Redundant Platinum Level Power Supplies




SYS-F628R2-FC0 (4 DP Nodes with Front I/O)

Key Features
• FatTwin™ Server; EACH NODE (x4 Hot-plug System Nodes):
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family
• 8 Hot-swap 2.5" SAS3 HDD Bays; SAS3 via Broadcom 3008
• 8 DIMM slots; up to 1TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
• 1 PCI-E 3.0 x16 Low-profile slot
• Ports: 2 GbE, 1 Video, 2 USB 3.0
Platinum Level • System management: Built-in Server management tool
   (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
• 8x 8cm 9.5K RPM Rear fans total in the system
• 1280W Redundant Platinum Level Power Supplies



F647G2-F Front
SYS-F648G2-FT+ / SYS-F648G2-FTPT+ / SYS-F648G2-FC0+ / SYS-F648G2-FC0PT+
(12 GPU/Coprocessor , Front I/O)

Key Features
• Outstanding high-density compute performance for Engineering and Scientific Research,
   Modeling, Simulation and HPC applications
• 2 Hot-plug System Nodes in 4U supporting 12 double-width GPU/Coprocessor , each Node:
• Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family
• 8 Hot-swap 2.5" SATA3 (-FT+/-FTPT+) or SAS3 (-FC0+/-FC0PT+) HDDs; SAS3 via Broadcom 3008
• 16 DIMM slots; up to 2TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
• 6 PCI-E 3.0 x16 support 6 Double-width GPU/Coprocessor ; and 2 PCI-E 3.0 x8 FHHL slots
• I/O ports: 2x GbE (-FT+/-FC0+)/10GBase-T (-FTPT+/-FC0PT+), 1x Video, 2x USB 3.0
TItaninum Level • System management: Built-in Server management tool
   (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
• 8 heavy duty rear fans, optional rear fan w/ Optimal Fan Speed Control
• 2000W Redundant Titanium Level (96%) High-efficiency Digital Power Supplies



F627R2-RTB+ Front
SYS-F627R2-RTB+ / SYS-F627R2-RT+ (4 DP Nodes)

X9 Key Features
• Up to 8 Hot-swap 2.5" SAS/SATA + 4 Hot-swap 2.5" SATA (front) HDDs per U
• Evolutionary 4U Twin Architecture that Offers Industry's Best Capacity and Efficiency
• 4x 1280W Redundant Platinum Level (95%) Digital Power Supplies
• 4 Hot-plug System Nodes in 4U, each Node:
• Dual Intel® Xeon® Processor E5-2600 or E5-2600 v2 Family; Socket R (LGA 2011)
• 16 DIMMs, up to 1TB, up to 1866MHz DDR3 memory
• 1 PCI-E 3.0 x16 (LP, F627R2-RTB+) / 2 PCI-E 3.0 x8 (LP, F627R2-RT+) + 1 Micro-LP Slot
Platinum Level • Dual LAN ports via Intel® i350 Gigabit Ethernet controller
• Server Management with Onboard IPMI 2.0 through Dedicated LAN Port
• SAS2 (6Gbps) via Broadcom 2208 controller; HW RAID 0, 1, 5, 6, 10, 50, 60 support
• Standard 19" Rack Cabinet support



F627R3 Front
SYS-F627R3-RTB+ / SYS-F627R3-R72B+ (4 DP Nodes)

Key Features
• Up to 8 Hot-swap 3.5" SATA (F627R3-RTB+) or SAS/SATA (F627R3-R72B+) HDDs per U
• Evolutionary 4U Twin Architecture that Offers Industry's Best Capacity and Efficiency
• 4x 1280W Redundant Platinum Level (95%) Digital Power Supplies
• 4 Hot-plug System Nodes in 4U, each Node:
• Dual Intel® Xeon® Processor E5-2600 or E5-2600 v2 Family; Socket R (LGA 2011)
• 16 DIMMs, up to 1TB, up to 1866MHz DDR3 memory
• 1 PCI-E 3.0 x16 (Low-profile) via riser card and 1 Micro-LP PCI-E 3.0 x8 Expansion Slot
Platinum Level • Dual LAN ports via Intel® i350 Gigabit Ethernet controller
• Server Management with Onboard IPMI 2.0 through Dedicated LAN Port
• SAS2 (6Gbps) via Broadcom 2208 controller; HW RAID 0, 1, 5, 6, 10, 50, 60 support (F627R3-R72B+)
• Standard 19" Rack Cabinet support



F617R2 Front
SYS-F617R2-RT+ / SYS-F617R2-R72+ (8 DP Nodes)

Key Features
• Up to 6 Hot-swap 2.5" SATA (F617R2-RT+) or SAS/SATA (F617R2-R72+) HDDs per 1/2 U
• Evolutionary 4U Twin Architecture that Offers Industry's Best Capacity and Efficiency
• 4x 1620W Redundant Platinum Level (94%+) Power Supplies
• 8 Hot-plug System Nodes in 4U, each Node:
• Dual Intel® Xeon® Processor E5-2600 or E5-2600 v2 Family; Socket R (LGA 2011)
• 16 DIMMs, up to 1TB, up to 1866MHz DDR3 memory
• 1 PCI-E 3.0 x16 (Low-profile) via riser card and 1 Micro-LP PCI-E 3.0 x8 Expansion Slot
Platinum Level • Dual LAN ports via Intel® i350 Gigabit Ethernet controller
• Server Management with Onboard IPMI 2.0 through Dedicated LAN Port
• SAS2 (6Gbps) via Broadcom 2208 controller; HW RAID 0, 1, 5, 6, 10, 50 support (F617R2-R72+)
• Standard 19" Rack Cabinet support



F617R2-F Front
SYS-F617R2-FT / SYS-F617R2-F73 (8 DP Nodes with Front I/O)

Key Features
• 2 Hot-swap 2.5" SATA (F617R2-FT) or SAS2 (F617R2-F73) HDDs per 1/2 U
• Evolutionary 4U Twin Architecture that Offers Industry's Best Capacity and Efficiency
• 4x 1620W Redundant Platinum Level (94%+) Digital Power Supplies
• 8 Hot-plug System Nodes in 4U, each Node:
• Dual Intel® Xeon® Processor E5-2600 or E5-2600 v2 Family; Socket R (LGA 2011)
• 8 DIMMs, up to 512GB, up to 1866MHz DDR3 memory
• 1 PCI-E 3.0 x16 (Low-profile) Expansion Slot via riser card
Platinum Level • Dual LAN ports via Intel® 82574L Gigabit Ethernet controller
• Server Management with Onboard IPMI 2.0 through Dedicated LAN Port
• SAS2 (6Gbps) via Broadcom 2308 controller; SW RAID 0, 1 support (F617R2-F73)
• Standard 19" Rack Cabinet support



F617R2-F Front
SYS-F617R2-F72+ (8 DP Nodes with Front I/O)

Key Features
• 4 Fixed 2.5" SAS2 HDDs per 1/2 U
• Evolutionary 4U Twin Architecture that Offers Industry's Best Capacity and Efficiency
• 4x 1620W Redundant Platinum Level (94%+) Digital Power Supplies
• 8 Hot-plug System Nodes in 4U, each Node:
• Dual Intel® Xeon® Processor E5-2600 or E5-2600 v2 Family; Socket R (LGA 2011)
• 16 DIMMs, up to 1TB, up to 1866MHz DDR3 memory
• 1 PCI-E 3.0 x16 (Low-profile) and 1 PCI-E 3.0 x8 (Low-profile) Expansion Slot via riser cards
Platinum Level • Dual LAN ports via Intel® i350 Gigabit Ethernet controller
• Server Management with Onboard IPMI 2.0 through Dedicated LAN Port
• SAS2 (6Gbps) via Broadcom 2208 controller; HW RAID 0, 1, 5, 6, 10 support
• Standard 19" Rack Cabinet support



F617R2-F Front
SYS-F617R2-FT+ / SYS-F617R2-FTPT+ / SYS-F617R3-FT+ / SYS-F617R3-FTPT+
(8 DP Nodes with Front I/O)

Key Features
• 2 (up to 4) Fixed 2.5" SATA (F617R2) or 3.5" SATA (F617R3) HDDs per 1/2 U
• Evolutionary 4U Twin Architecture that Offers Industry's Best Capacity and Efficiency
• 4x 1620W Redundant Platinum Level (94%+) Digital Power Supplies
• 8 Hot-plug System Nodes in 4U, each Node:
• Dual Intel® Xeon® Processor E5-2600 or E5-2600 v2 Family; Socket R (LGA 2011)
• 16 DIMMs, up to 1TB, up to 1866MHz DDR3 memory
• 1 PCI-E 3.0 x16 (Low-profile) and 1 PCI-E 3.0 x8 (Low-profile) Expansion Slot via riser card
Platinum Level • Dual LAN ports via Intel® i350 Gigabit Ethernet controller
• Server Management with Onboard IPMI 2.0 through Dedicated LAN Port
• SATA3 (6Gbps) and SATA2 (3Gbps); RAID 0, 1 support
• Standard 19" Rack Cabinet support



F617R2 Front
SYS-F617R3-FT (8 DP Nodes with Front I/O)

Key Features
• Up to 2 Fixed 3.5" SATA HDDs per 1/2 U
• Evolutionary 4U Twin Architecture that Offers Industry's Best Capacity and Efficiency
• 4x 1620W Redundant Platinum Level (94%+) Power Supplies
• 8 Hot-plug System Nodes in 4U, each Node:
• Dual Intel® Xeon® Processor E5-2600 or E5-2600 v2 Family; Socket R (LGA 2011)
• 8 DIMMs, up to 512GB, up to 1866MHz DDR3 memory
Platinum Level • 1 PCI-E 3.0 x16 (Low-profile) expansion slot via riser card
• Dual LAN ports via Intel® 82574L Gigabit Ethernet controller
• Server Management with Onboard IPMI 2.0 through Dedicated LAN Port
• Standard 19" Rack Cabinet support



F627R3 Front
SYS-F627R3-FT / SYS-F627R3-F73 (4 DP Nodes with Front I/O)

Key Features
• Up to 4 Hot-swap 3.5" SATA (F627R3-FT) or SAS/SATA (F627R3-F73) HDDs per U
• Evolutionary 4U Twin Architecture that Offers Industry's Best Capacity and Efficiency
• 4x 1280W Redundant Platinum Level (95%) Digital Power Supplies
• 4 Hot-plug System Nodes in 4U, each Node:
• Dual Intel® Xeon® Processor E5-2600 or E5-2600 v2 Family; Socket R (LGA 2011)
• 8 DIMMs, up to 512GB, up to 1866MHz DDR3 memory
• 1 PCI-E 3.0 x16 (Low-profile) expansion slot via riser card
Platinum Level • Dual LAN ports via Intel® 82574L Gigabit Ethernet controller
• Server Management with Onboard IPMI 2.0 through Dedicated LAN Port
• Optional SAS2 (6Gbps) via Broadcom 2308 controller; SW RAID 0, 1, 10 support (F627R3-F73)
• Standard 19" Rack Cabinet support



F627R2-F73 Front
SYS-F627R2-F73 (4 DP Nodes with Front I/O)

Key Features
• Up to 8 Hot-swap 2.5" SAS HDDs per U
• Evolutionary 4U Twin Architecture that Offers Industry's Best Capacity and Efficiency
• 4x 1280W Redundant Platinum Level (95%) Digital Power Supplies
• 4 Hot-plug System Nodes in 4U, each Node:
• Dual Intel® Xeon® Processor E5-2600 or E5-2600 v2 Family; Socket R (LGA 2011)
• 8 DIMMs, up to 512GB, up to 1866MHz DDR3 memory
• 1 PCI-E 3.0 x 16 (LP) expansion slot via riser card
Platinum Level • Dual LAN ports via Intel® 82574L Gigabit Ethernet controller
• Server Management with Onboard IPMI 2.0 through Dedicated LAN Port
• SAS2 (6Gbps) via Broadcom 2308 controller; SW RAID 0, 1 support
• Standard 19" Rack Cabinet support



F627R2 Front
SYS-F627R2-FT+ / SYS-F627R2-FTPT+ / SYS-F627R2-F72+ / SYS-F627R2-F72PT+
(4 DP Nodes with Front I/O)

Key Features
• Up to 6 Hot-swap 2.5" SATA (-FT+/-FTPT+) or SAS/SATA (-F72+/-F72PT+) HDDs per U
• Evolutionary 4U Twin Architecture that Offers Industry's Best Capacity and Efficiency
• 4x 1280W Redundant Platinum Level (95%) Digital Power Supplies
• 4 Hot-plug System Nodes in 4U, each Node:
• Dual Intel® Xeon® Processor E5-2600 or E5-2600 v2 Family; Socket R (LGA 2011)
• 16x DIMMs, up to 1TB, up to 1866MHz DDR3 memory
• 1 PCI-E 3.0 x 16 (LP), 1 PCI-E 3.0 x8 (LP), and 1 PCI-E 3.0 x4 (LP) expansion slots
• Dual LAN ports via Intel® i350 Gigabit Ethernet (F627R2-FT+/-F72+)
Platinum Level • Dual LAN ports via Intel® X540 10GBase-T (F627R2-FTPT+/-F72PT+)
• Server Management with Onboard IPMI 2.0 through Dedicated LAN Port
• Optional SAS2 (6Gbps) via Broadcom 2208 controller; HW RAID 0, 1, 5, 6, 10, 50, 60 support
• Standard 19" Rack Cabinet support



F627R3-F Front
SYS-F627R3-FT+ / SYS-F627R3-FTPT+ / SYS-F627R3-F72+ / SYS-F627R3-F72PT+
(4 DP Nodes with Front I/O)

Key Features
• Up to 2 Hot-swap 3.5" SATA (-FT+/-FTPT+) or SAS/SATA (-F72+/-F72PT+) HDDs per U
• Evolutionary 4U Twin Architecture that Offers Industry's Best Capacity and Efficiency
• 4x 1280W Redundant Platinum Level (95%) Digital Power Supplies
• 4 Hot-plug System Nodes in 4U, each Node:
• Dual Intel® Xeon® Processor E5-2600 or E5-2600 v2 Family; Socket R (LGA 2011)
• 16 DIMMs, up to 1TB, up to 1866MHz DDR3 memory
• 1 PCI-E 3.0 x 16 (LP), 1 PCI-E 3.0 x8 (LP), and 1 PCI-E 2.0 x4 (LP) expansion slots
• Dual LAN ports via Intel® i350 Gigabit Ethernet (F627R3-FT+/-F72+)
Platinum Level • Dual LAN ports via Intel® X540 10GBase-T (F627R3-FTPT+/-F72PT+)
• Server Management with Onboard IPMI 2.0 through Dedicated LAN Port
• Optional SAS2 (6Gbps) via Broadcom 2208 controller; HW RAID 0, 1 support
• Standard 19" Rack Cabinet support



F627G3-F Front
SYS-F627G3-FT+ / SYS-F627G3-FTPT+ / SYS-F627G3-F73+ / SYS-F627G3-F73PT+
(12 GPU/Coprocessor MIC, Front I/O)

Key Features
• Outstanding high-density compute performance for Engineering and Scientific Research,
   Modeling, Simulation and HPC applications
• 4x 1620W Redundant Platinum Level Power Supplies
• 4 Hot-plug System Nodes in 4U supporting 12 double-width GPU/Coprocessor MIC, each Node:
• Up to 2 Hot-swap3.5" SATA (-FT+/-FTPT+) or SAS2 (-F73+/-F73PT+) HDDs per U
• Dual Intel® Xeon® Processor E5-2600 or E5-2600 v2 Family; Socket R (LGA 2011)
• 16 DIMMs, up to 1TB, up to 1866MHz DDR3 memory
• 3 PCI-E 3.0 x16 support 3 Double-width GPU/MIC; and 2 PCI-E 3.0 x8 Low-profile slots
Platinum Level • Dual LAN ports via Intel® i350 Gigabit Ethernet (F627G3-FT+/-F73+)
• Dual LAN ports via Intel® X540 10GBase-T (F627G3-FTPT+/-F73PT+)
• Server Management with Onboard IPMI 2.0 through Dedicated LAN Port
• Standard 19" Rack Cabinet support



F627G2-F Front
SYS-F627G2-FT+ / SYS-F627G2-FTPT+ / SYS-F627G2-F73+ / SYS-F627G2-F73PT+
(12 GPU/Coprocessor MIC, Front I/O)

Key Features
• Outstanding high-density compute performance for Engineering and Scientific Research,
   Modeling, Simulation and HPC applications
• 4x 1620W Redundant Platinum Level Power Supplies
• 4 Hot-plug System Nodes in 4U supporting 12 double-width GPU/Coprocessor MIC, each Node:
• Up to 6 Hot-swap 2.5" SATA (-FT+/-FTPT+) or SAS2 (-F73+/-F73PT+) HDDs per U
• Dual Intel® Xeon® Processor E5-2600 or E5-2600 v2 Family; Socket R (LGA 2011)
• 16 DIMMs, up to 1TB, up to 1866MHz DDR3 memory
• 3 PCI-E 3.0 x16 support 3 Double-width GPU/MIC; and 2x PCI-E 3.0 x8 Low-profile slots
Platinum Level • Dual LAN ports via Intel® i350 Gigabit Ethernet (F627G2-FT+/-F73+)
• Dual LAN ports via Intel® X540 10GBase-T (F627G2-FTPT+/-F73PT+)
• Server Management with Onboard IPMI 2.0 through Dedicated LAN Port
• Standard 19" Rack Cabinet support



F647G2-F Front
SYS-F647G2-FT+ / SYS-F647G2-FTPT+ / SYS-F647G2-F73+ / SYS-F647G2-F73PT+
(12 GPU/Coprocessor , Front I/O)

Key Features
• Outstanding high-density compute performance for Engineering and Scientific Research,
   Modeling, Simulation and HPC applications
• 4x 2000W Redundant Platinum Level Power Supplies
• 2 Hot-plug System Nodes in 4U supporting 12 double-width GPU/Coprocessor , each Node:
• Up to 6 Hot-swap 2.5" SATA (-FT+/-FTPT+) or SAS2 (-F73+/-F73PT+) HDDs per U
• Dual Intel® Xeon® Processor E5-2600 or E5-2600 v2 Family; Socket R (LGA 2011)
• 16 DIMMs, up to 1TB, up to 1866MHz DDR3 memory
• 6 PCI-E 3.0 x16 support 6 Double-width GPU/Coprocessor ; and 2 PCI-E 3.0 x8 Low-profile slots
Platinum Level • Dual LAN ports via Intel® i350 Gigabit Ethernet (F627G2-FT+/-F73+)
• Dual LAN ports via Intel® X540 10GBase-T (F627G2-FTPT+/-F73PT+)
• Server Management with Onboard IPMI 2.0 through Dedicated LAN Port
• Standard 19" Rack Cabinet support



Terms & Conditions   |   Privacy   |   Investor Relations   |   Jobs   |   Site Map   |   Follow Us
SuperServer® | Motherboards | Chassis | SuperRack® | SuperBlade® | Embedded | Networking | Storage | Accessories | AMD Solutions | Power Supplies

Copyright © 2017 Super Micro Computer, Inc. Information in this document is subject to change without notice.
Other products and companies referred to herein are trademarks or registered trademarks of their respective companies or mark holders.
