WIO Servers

Supermicro WIO SuperServer® systems offer a wide range of I/O options to deliver truly optimized systems for specific requirements. Users can optimize the storage and networking alternatives to accelerate performance, increase efficiency and find the perfect fit for their applications. In addition to enabling customizable configurations and optimization for multiple application requirements, Supermicro WIO SuperServers also provide attractive cost advantages and investment protection.

The Supermicro WIO SuperServer® product family supports up to: 3TB DDR4-2933MHz ECC memory in 12 DIMM slots with support for Intel(r) Optane(tm) DC Persistent Memory, 3/6 Add-on Cards in 1U/2U, 12 SATA 3.0 (6Gbps) ports with Intel® C620 controller, hot-swap 2.5" or 3.5" drive bays, SATA3 and NVMe hybrid ports, optional NVMe drives, LAN options up to 2x 10GBase-T or 2x 1GbE ports, redundant Titanium Level (96%) power supplies, integrated IPMI 2.0 with KVM over dedicated LAN, and dual or single 2nd generation Intel® Xeon® Scalable processors up to 28 cores and 205W TDP.

Supermicro WIO SuperServers are optimized for General Purpose, ERP/MRP, and Network and Security Appliance Applications and used as Firewall, Mail and VPN servers.

Support up to:

  • 28 Cores per CPU
  • 3TB DDR4-2933MHz ECC memory in 12 DIMM slots with support for Intel® Optane™ DC Persistent Memory
  • 205W per socket
  • 3/6 PCI-E 3.0 x16 slots (1U/2U)
  • NVMe
  • Redundant 1200W high efficiency (96%) power supplies

Resources

Product Brief

SYS-1029P-WTRT
SYS-1029P-WTRT
WIO, Flexible I/O • 10 Hot-swap 2.5" bays • 2 NVMe support
  • Cloud and other virtualization needs, hosting & application delivery, database processing & storage, simulation, automation
  • Dual Socket P (LGA 3647) support: 2nd Gen. Intel® Xeon® Scalable processors; dual UPI up to 10.4GT/s
  • 12 DIMMs; up to 3TB 3DS ECC DDR4-2933 MHz RDIMM/LRDIMM
  • Supports Intel® Optane™ DCPMM*
  • 10 Hot-swap 2.5" drive bays; 8 SATA3 + 2 NVMe/SATA3 hybrid ports
  • 2 PCI-E 3.0 x16 (FHHL), 1 PCI-E 3.0 x8 (LP), 1 PCI-E 3.0 x16 for AOM, 1 PCI-E 3.0 x4 NVMe M.2 slot
  • 2x 10GBase-T ports via Intel C622, 1 Dedicated IPMI port
  • 1 VGA, 6 USB 3.0 (4 rear, 2 front via header)
  • 4 Counter-rotating 4cm PWM cooling fans
  • 750W Redundant Platinum Level Power Supplies

*Contact your Supermicro sales rep for more info.

SYS-1029P-WTR
SYS-1029P-WTR
WIO, Flexible I/O • 8 Hot-swap 2.5" bays • 1 Slim DVD-ROM (Opt.)
  • Web Server, FireWall Applications, DNS, Print, Login, Gateway, Compact Network Appliance, Cloud Computing
  • Dual Socket P (LGA 3647) support: 2nd Gen. Intel® Xeon® Scalable processors; dual UPI up to 10.4GT/s
  • 12 DIMMs; up to 3TB 3DS ECC DDR4-2933 MHz RDIMM/LRDIMM
  • Supports Intel® Optane™ DCPMM*
  • 8 Hot-swap 2.5" drive bays; 1 slim DVD-ROM bay (option)
  • 2 PCI-E 3.0 x16 (FHHL), 1 PCI-E 3.0 x8 (LP), 1 PCI-E 3.0 x16 for AOM, 1 PCI-E 3.0 x4 NVMe M.2 slot
  • 2x 1GbE ports via Intel C621, 1 Dedicated IPMI port
  • 1 VGA, 6 USB 3.0 (4 rear, 2 via header)
  • 4 Counter-rotating 4cm PWM cooling fans
  • 750W Redundant Platinum Level Power Supplies

*Contact your Supermicro sales rep for more info.

SYS-1029P-WT
SYS-1029P-WT
WIO, Flexible I/O • 8 Hot-swap 2.5" bays • 1 Slim DVD-ROM (Opt.)
  • Web Server, FireWall Applications, DNS, Print, Login, Gateway, Compact Network Appliance, Cloud Computing
  • Dual Socket P (LGA 3647) support: 2nd Gen. Intel® Xeon® Scalable processors; dual UPI up to 10.4GT/s
  • 12 DIMMs; up to 3TB 3DS ECC DDR4-2933 MHz RDIMM/LRDIMM
  • Supports Intel® Optane™ DCPMM*
  • 8 Hot-swap 2.5" drive bays; 1 slim DVD-ROM bay (option)
  • 2 PCI-E 3.0 x16 (FHHL), 1 PCI-E 3.0 x8 (LP), 1 PCI-E 3.0 x16 for AOM, 1 PCI-E 3.0 x4 NVMe M.2 slot
  • 2x 1GbE ports via Intel C621, 1 Dedicated IPMI port
  • 1 VGA, 6 USB 3.0 (4 rear, 2 via header)
  • 4 Counter-rotating 4cm PWM cooling fans
  • 600W Multi Output Platinum Level Power Supply

*Contact your Supermicro sales rep for more info.

SYS-6019P-WT8
SYS-6019P-WT8
WIO, Flexible I/O • 8x 3.5" + 2x 2.5" bays
  • Web Server, FireWall Applications, DNS, Print, Login, Gateway, Compact Network Appliance, Cloud Computing
  • Dual Socket P (LGA 3647) support: 2nd Gen. Intel® Xeon® Scalable processors; dual UPI up to 10.4GT/s
  • 12 DIMMs; up to 3TB 3DS ECC DDR4-2933 MHz RDIMM/LRDIMM
  • Supports Intel® Optane™ DCPMM*
  • 8 Fixed 3.5" + 2 Fixed 2.5" drive bays
  • 2 PCI-E 3.0 x16 (FHHL), 1 PCI-E 3.0 x8 (LP), 1 PCI-E 3.0 x16 for AOM, 1 PCI-E NVMe M.2 SSD
  • 2x 1GbE ports via Intel C621, 1 Dedicated IPMI port
  • 1 VGA, 4 USB 3.0 (rear)
  • 6 Counter-rotating 4cm PWM cooling fans
  • 650W/600W Multi-output Platinum Level Power Supply

*Contact your Supermicro sales rep for more info.

SYS-6019P-WTR
SYS-6019P-WTR
WIO, Flexible I/O • 4 Hot-swap 3.5" bays
  • Web Server, FireWall Applications, DNS, Print, Login, Gateway, Compact Network Appliance, Cloud Computing
  • Dual Socket P (LGA 3647) support: 2nd Gen. Intel® Xeon® Scalable processors; dual UPI up to 10.4GT/s
  • 12 DIMMs; up to 3TB 3DS ECC DDR4-2933 MHz RDIMM/LRDIMM
  • Supports Intel® Optane™ DCPMM*
  • 4 Hot-swap 3.5" drive bays
  • 2 PCI-E 3.0 x16 (FHHL), 1 PCI-E 3.0 x8 (LP), 1 PCI-E 3.0 x16 for AOM, 1 PCI-E 3.0 x4 NVMe M.2 slot
  • 2x 1GbE ports via Intel C621, 1 Dedicated IPMI port
  • 1 VGA, 4 USB 3.0 (rear)
  • 4 Counter-rotating 4cm PWM cooling fans
  • 750W Redundant Platinum Level Power Supplies

*Contact your Supermicro sales rep for more info.

SYS-6019P-WT
SYS-6019P-WT
WIO, Flexible I/O • 4 Hot-swap 3.5" bays
  • Web Server, FireWall Applications, DNS, Print, Login, Gateway, Compact Network Appliance, Cloud Computing
  • Dual Socket P (LGA 3647) support: 2nd Gen. Intel® Xeon® Scalable processors; dual UPI up to 10.4GT/s
  • 12 DIMMs; up to 3TB 3DS ECC DDR4-2933 MHz RDIMM/LRDIMM
  • Supports Intel® Optane™ DCPMM*
  • 4 Hot-swap 3.5" drive bays
  • 2 PCI-E 3.0 x16 (FHHL), 1 PCI-E 3.0 x8 (LP), 1 PCI-E 3.0 x16 for AOM, 1 PCI-E 3.0 x4 NVMe M.2 slot
  • 2x 1GbE ports via Intel C621, 1 Dedicated IPMI port
  • 1 VGA, 4 USB 3.0 (rear)
  • 4 Counter-rotating 4cm PWM cooling fans
  • 600W Multi Output Platinum Level Power Supply

*Contact your Supermicro sales rep for more info.

SYS-1019P-WTR
SYS-1019P-WTR
WIO, Flexible I/O, UP • 10 Hot-swap 2.5" bays • 2 NVMe w/ AOC opt.
  • Database Processing and Storage, Data Center Applications
  • Single Socket P (LGA 3647) support: 2nd Gen. Intel® Xeon® Scalable processors
  • 6 DIMMs; up to 1.5TB 3DS ECC DDR4-2933 MHz RDIMM/LRDIMM
  • 10 Hot-swap 2.5" drive bays, M.2 mini-PCI-e support
  • 2 PCI-E 3.0 x16 (FHFL) slots, 1 PCI-E 3.0 x8 (LP) slot
  • 2x 10GBase-T ports via Intel X557, 1 Dedicated IPMI port
  • 1 VGA, 2 USB 3.0 (rear), 2 USB 2.0 (rear)
  • 5 Counter-rotating 4cm PWM cooling fans
  • 500W Redundant Platinum Level Power Supplies
SYS-5019P-WT
SYS-5019P-WT
WIO, Flexible I/O, UP • 4 Hot-swap 3.5" bays
  • Database Processing and Storage, Data Center / Firewall Applications
  • Single Socket P (LGA 3647) support: 2nd Gen. Intel® Xeon® Scalable processors
  • 6 DIMMs; up to 1.5TB 3DS ECC DDR4-2933 MHz RDIMM/LRDIMM
  • 4 Hot-swap 3.5" drive bays, 1 slim DVD-ROM bay, M.2 mini-PCI-e support
  • 2 PCI-E 3.0 x16 (FHFL) slots, 1 PCI-E 3.0 x8 (LP) slot
  • 2x 10GBase-T ports via Intel X557, 1 Dedicated IPMI port
  • 1 VGA, 2 USB 3.0 (rear), 2 USB 2.0 (rear)
  • 5 Counter-rotating 4cm PWM cooling fans
  • 600W Multi Output Platinum Level Power Supply
SYS-5019P-WTR
SYS-5019P-WTR
WIO, Flexible I/O, UP • 4 Hot-swap 3.5" bays
  • Database Processing and Storage, Data Center / Firewall Applications
  • Single Socket P (LGA 3647) support: 2nd Gen. Intel® Xeon® Scalable processors
  • 6 DIMMs; up to 1.5TB 3DS ECC DDR4-2933 MHz RDIMM/LRDIMM
  • 4 Hot-swap 3.5" drive bays, M.2 mini-PCI-e support
  • 2 PCI-E 3.0 x16 (FHFL) slots, 1 PCI-E 3.0 x8 (LP) slot
  • 2x 10GBase-T ports via Intel X557, 1 Dedicated IPMI port
  • 1 VGA, 2 USB 3.0 (rear), 2 USB 2.0 (rear)
  • 5 Counter-rotating 4cm PWM cooling fans
  • 500W Redundant Platinum Level Power Supplies
SYS-5029P-WTR
SYS-5029P-WTR
WIO, Flexible I/O, UP • 8 Hot-swap 3.5" bays
  • Database Processing and Storage, Connectivity/Storage Computer Nodes, Data Warehouse
  • Single Socket P (LGA 3647) support: 2nd Gen. Intel® Xeon® Scalable processors
  • 6 DIMMs; up to 1.5TB 3DS ECC DDR4-2933 MHz RDIMM/LRDIMM
  • 8 Hot-swap 3.5" drive bays, 1 Slim DVD-ROM bay, M.2 mini-PCI-e support
  • 4 PCI-E 3.0 x8 (FHFL) slots, 1 PCI-E 3.0 x8 (LP) slot
  • 2x 10GBase-T ports via Intel X557, 1 Dedicated IPMI port
  • 1 VGA, 1 COM, 2 USB 3.0 (rear), 2 USB 2.0 (rear)
  • 3 Hot-swap 8cm PWM cooling fans
  • 500W Redundant Platinum Level Power Supplies
SYS-6029P-WTRT
SYS-6029P-WTRT
WIO, Flexible I/O • 12 Hot-swap 3.5" bays
  • Web Server, FireWall Applications, DNS, Print, Login, Gateway, Compact Network Appliance, Cloud Computing
  • Dual Socket P (LGA 3647) support: 2nd Gen. Intel® Xeon® Scalable processors; dual UPI up to 10.4GT/s
  • 12 DIMMs; up to 3TB 3DS ECC DDR4-2933 MHz RDIMM/LRDIMM
  • Supports Intel® Optane™ DCPMM*
  • 12 Hot-swap 3.5" drive bays with SES2 and Mini-i-Pass: 8 SATA3 + 4 NVMe/SATA3 hybrid ports
  • 1 PCI-E 3.0 x16 (FHHL), 2 PCI-E 3.0 x8 (FHHL), 2 PCI-E 3.0 x8 (LP), 1 PCI-E 3.0 x16 for AOM, 1 PCI-E 3.0 x4 NVMe M.2 slot
  • 2x 10GBase-T ports via Intel C622, 1 Dedicated IPMI port
  • 1 VGA, 4 USB 3.0 (rear)
  • 3 high-performance 8cm heavy duty PWM fans
  • 1200W Redundant Titanium Level (96%) Power Supplies

*Contact your Supermicro sales rep for more info.

SYS-6029P-WTR
SYS-6029P-WTR
WIO, Flexible I/O • 8 Hot-swap 3.5" and • 2 Fixed 3.5" bays
  • Web Server, FireWall Applications, DNS, Print, Login, Gateway, Compact Network Appliance, Cloud Computing
  • Dual Socket P (LGA 3647) support: 2nd Gen. Intel® Xeon® Scalable processors; dual UPI up to 10.4GT/s
  • 12 DIMMs; up to 3TB 3DS ECC DDR4-2933 MHz RDIMM/LRDIMM
  • Supports Intel® Optane™ DCPMM*
  • 8 Hot-swap 3.5" drive bays with SGPIO, 2 Fixed 3.5" drive bays
  • 4 PCI-E 3.0 x8 (FHHL), 2 PCI-E 3.0 x8 (LP), 1 PCI-E 3.0 x16 for AOM, 1 PCI-E 3.0 x4 NVMe M.2 slot
  • 2x 1GbE ports via Intel C621, 1 Dedicated IPMI port
  • 1 VGA, 4 USB 3.0 (rear)
  • 3 high-performance 8cm heavy duty PWM fans
  • 1000W Redundant Titanium Level (96%) Power Supplies

*Contact your Supermicro sales rep for more info.

SYS-5019S-WR
SYS-5019S-WR
X11SSW-F + • SC815TQC-R504WB
  • HA, VM, Communication, WIO, Flexible I/O
  • Single Socket H4 (LGA 1151) supports: Intel® Xeon® processor E3-1200 v6/v5 family, Intel® 7th/6th Gen Core i3 series processor, Intel® Celeron® and Intel® Pentium processors
  • Intel® C236 chipset
  • 4x 3.5" Hot-swap SATA3 bays w/ RAID
  • 2 PCI-E 3.0 x8, 1 PCI-E 3.0 x4 (in x8) AOC Slot; 1 M.2 connector
  • Up to 64GB DDR4 2400MHz ECC UDIMMs in 4 sockets
  • 2 RJ45 1GbE LAN ports (Intel® i210-AT)
  • Integrated IPMI 2.0 with KVM and Dedicated LAN
  • 1 VGA, 2 COM, 2 USB 3.0 (rear), 2 USB 2.0 (rear)
  • 2 SuperDOM ports with built-in power; TPM header
  • 500W (1+1) Redundant High-efficiency Power Supplies
SYS-1019S-WR
SYS-1019S-WR
X11SSW-F + • SC514-R407W
  • Appliance Server, WIO, Embedded Applications
  • Single Socket H4 (LGA 1151) supports: Intel® Xeon® processor E3-1200 v6/v5 family, Intel® 7th/6th Gen Core i3 series processor, Intel® Celeron® and Intel® Pentium processors
  • Intel® C236 chipset
  • 2x 2.5" internal fixed SATA3 drive bays
  • 1 PCI-E 3.0 x16 or 2 PCI-E 3.0 x8 Left Riser slot; 1 PCI-E 3.0 x4 (in x8); 1 M.2 connector
  • Up to 64GB DDR4 2400MHz ECC UDIMMs in 4 sockets
  • 2 RJ45 1GbE LAN ports (Intel® i210-AT)
  • Integrated IPMI 2.0 with KVM and Dedicated LAN
  • 1 VGA, 1 COM, 2 USB 3.0 (rear), 2 USB 2.0 (rear)
  • 2 SuperDOM ports with built-in power; TPM header
  • 400W Redundant High-efficiency Power Supplies
SYS-1018R-WR
SYS-1018R-WR
Embedded Appliances
  • 1U Appliance Server, WIO, Embedded Applications
  • Single Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family; QPI up to 9.6GT/s
  • 2 fixed 2.5" SATA3 drive bays
  • 8 DIMM slots; up to 1TB ECC 3DS LRDIMM or RDIMM DDR4-2400
  • 2 PCI-E 3.0 x16 left riser slot, 1 PCI-E 3.0 x8 LP slot
  • 2 GbE, 1 Video, 2 COM, 4 USB 3.0, 2 USB 2.0
  • System management: Built-in Server management tool (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
  • 4 PWM Cooling fans; 2 optional fans for AOC cooling
  • 400W Redundant Platinum Level Power Supplies
SYS-1028R-WMR
SYS-1028R-WMR

/ SYS-1028R-WMRT

Short Depth 16.9", WIO • Flexible I/O
  • Cloud and other virtualization needs, hosting & application delivery, database processing & storage, simulation, automation
  • Dual socket R3 (LGA 2011) supports: Intel® Xeon® processor E5-2600 v4/v3 family; QPI up to 9.6GT/s
  • 2 Fixed 2.5" drive bays w/ bracket
  • 16 DIMM slots; up to 2TB ECC 3DS LRDIMM or RDIMM DDR4-2400
  • 2 PCI-E 3.0 x16 and 1 PCI-E 3.0 x8 (in x16) slots
  • 2 SuperDOM, 1 VGA, 1 COM, 2 USB 3.0, 4 USB 2.0
  • System management: Built-in Server management tool (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
  • 4x 40x56mm PWM fan; 2x fans for AOC cooling
  • 400W (1+1) Redundant SuperCompact Short-depth AC-DC Gold-level power supply with PMBus and I²C
SYS-1018R-WC0R
SYS-1018R-WC0R
WIO, Flexible I/O • Storage Array
  • Cloud and other virtualization needs, hosting & application delivery, database processing & storage, simulation, automation
  • Single Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family; QPI up to 9.6GT/s
  • 8 Hot-swap 2.5" SAS3 + 2 Hot-swap 2.5" SATA3 drive bays
  • 8 DIMM slots; up to 1TB ECC 3DS LRDIMM or RDIMM DDR4-2400
  • 2 PCI-E 3.0 x16 and 1 PCI-E 3.0 x8 (in x16) slots
  • 2 GbE, 1 Video, 2 COM, 2 USB 3.0, 4 USB 2.0
  • System management: Built-in Server management tool (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
  • 3 PWM Cooling fans
  • 700W/750W Redundant Platinum Level Power Supplies
SYS-1028R-WTR
SYS-1028R-WTR

/ SYS-1028R-WTRT / SYS-1028R-WC1R / SYS-1028R-WC1RT

10 Hot-swap 2.5" bays • SAS3 via Broadcom 3108, • 2 NVMe support ("C")
  • Cloud and other virtualization needs, hosting & application delivery, database processing & storage, simulation, automation
  • Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family; QPI up to 9.6GT/s
  • 10 Hot-swap 2.5" SAS/SATA drive bays; SAS3 via Broadcom 3108 ("C" SKUs), 2 Opt. NVMe drive support ("C" SKUs)
  • 16 DIMM slots; up to 2TB ECC 3DS LRDIMM or RDIMM DDR4-2400
  • 2 PCI-E 3.0 x16 (FHHL) via riser card, 1 PCI-E 3.0 x8 Mezzanine for HBA cards
  • 2 GbE/10GBase-T ("RT"), 1 Video, 1 COM, 6 USB 3.0
  • System management: Built-in Server management tool (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
  • 5x 40mm Counter-rotating PWM fans
  • 750W Redundant Platinum Level Power Supplies
SYS-6018R-WTR
SYS-6018R-WTR

/ SYS-6018R-WTRT

WIO, Flexible I/O
  • Cloud and other virtualization needs, hosting & application delivery, database processing & storage, simulation, automation
  • Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family; QPI up to 9.6GT/s
  • 4 Hot-swap 3.5" SAS/SATA drive bays for Customizable storage
  • 16 DIMM slots; up to 2TB ECC 3DS LRDIMM or RDIMM DDR4-2400
  • Riser card support: Left side - 2 PCI-E 3.0 x16 slots
  • 2 GbE/10GBase-T (WTRT), 1 Video, 1 Serial, 6 USB 3.0
  • System management: Built-in Server management tool (IPMI 2.0, KVM/media over LAN) w/ dedicated LAN port
  • 5 Counter-rotating PWM fans
  • 750W Redundant Platinum Level Power Supplies
SYS-6028R-TDWNR
SYS-6028R-TDWNR
4 Internal NVMe ports • Data Center Optimized • WIO, Flexible I/O
  • 2U WIO Server
  • Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family; QPI up to 9.6GT/s
  • 8x 3.5" Hot-swap SATA3 + 4x 2.5" NVMe drive bays
  • 16 DIMM slots; up to 2TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
  • 1 PCI-E 3.0 x16 (FHHL), 2x PCI-E 3.0 x8 (FHHL), and 1x PCI-E 3.0 (LP) via riser card
  • 2 GbE, 1 Video, 2 USB 3.0, 2 USB 2.0
  • System management: Built-in Server management tool (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
  • 3x 80mm PWM fans w/ optimal fan speed control
  • 920W Redundant Platinum Level Power Supplies
SYS-5028R-WR
SYS-5028R-WR
WIO, Flexible I/O
  • Cloud and other virtualization needs, hosting & application delivery, database processing & storage, simulation, automation
  • Single Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family; QPI up to 9.6GT/s
  • 8 Hot-swap 3.5" SATA3 drive bays
  • 8 DIMM slots; up to 1TB ECC 3DS LRDIMM or RDIMM DDR4-2400
  • 4 PCI-E 3.0 x8 (FH) and 1 PCI-E 3.0 x8 (LP) slots via riser card
  • 2 GbE, 1 Video, 1 COM/Serial, 2 USB 2.0
  • System management: Built-in Server management tool (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
  • 3 Counter-rotating PWM Cooling fans
  • 500W Redundant Platinum Level Power Supplies
SYS-6028R-WTR
SYS-6028R-WTR

/ SYS-6028R-WTRT

WIO, Flexible I/O
  • 2U Mainstream WIO Server
  • Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family; QPI up to 9.6GT/s
  • 8 Hot-swap 3.5" drive bays ready for flexible storage support
  • 16 DIMM slots; up to 2TB ECC 3DS LRDIMM or RDIMM DDR4-2400
  • 4 PCI-E 3.0 x8 (2 FHFL, 2 FHHL), 2 PCI-E 3.0 (LP) slots via riser card
  • 2 GbE/10GBase-T (WTRT), 1 Video, 2 COM, 6 USB 3.0
  • System management: Built-in Server management tool (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
  • 3 heavy duty fans w/ optimal fan speed control
  • 740W Redundant Platinum Level Power Supplies
SYS-1028R-WTNR
SYS-1028R-WTNR

/ SYS-1028R-WTNRT

WIO, Flexible I/O • 10x 2.5" Hot-swap bays • 2 NVMe support
  • Cloud and other virtualization needs, hosting & application delivery, database processing & storage, simulation, automation
  • Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family; QPI up to 9.6GT/s
  • 10x 2.5" Hot-swap HDD Bays; 8 SATA3 + 2 NVMe/SATA3 hybrid ports
  • 16 DIMM slots; up to 2TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
  • 2 PCI-E 3.0 x16 and 1 PCI-E 3.0 x8 (in x16) slots
  • 2 GbE (1028R-WTNR) / 10GBase-T (1028R-WTNRT), 1 Video, 1 COM, 6 USB 3.0
  • System management: Built-in Server management tool (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
  • 5x 40mm Counter-rotating PWM fans
  • 700W/750W Redundant Platinum Level Power Supplies
SYS-1027R-WRF
SYS-1027R-WRF
X9DRW-iF + SC113TQ-R700WB
  • Cloud and other virtualization needs, hosting & application delivery, database processing & storage, simulation, automation
  • Dual Intel® Xeon® processor E5-2600 or E5-2600 v2 family; Socket R (LGA 2011)
  • 8 Hot-swap 2.5" SATA HDD Bays for Customizable storage
  • 16 DIMMs support up to 1TB DDR3 1866MHz reg. ECC memory
  • Riser card support: Left side - 2 PCI-E 3.0 x16 slots
  • I/O ports: 2 GbE, 1 Video, 1 COM/Serial, 6 USB 2.0
  • System management: Built-in Server management tool (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
  • 5x 4cm Counter-rotating PWM fans
  • 700W Redundant Gold Level Power Supplies
SYS-5019C-WR
SYS-5019C-WR
  • HA, High flexibility, VM, Communication, Application and data serving, Appliance Server
  • Single socket H4 (LGA 1151) supports Intel® Xeon® Processor E-2100 series, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C246 chipset
  • Up to 128GB unbuffered ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots
  • 2x 1GbE LAN ports (Intel i210-AT)
  • 1 PCI-E 3.0 x16 slot or 2 PCI-E 3.0 x8, 1 PCI-E 3.0 x4 (in x8) slot
  • 4 Hot-swap 3.5" drive bays
  • M.2: 1 SATA/PCI-E 3.0 x4 and 1 PCI-E 3.0 x4, 2260/2280/22110, M-Key
  • 2 USB 3.1 ports (rear), 2 USB 2.0 (rear)
  • 1 VGA port, 2 COM, 1 TPM 2.0 (header)
  • 500W Redundant Platinum Level power supplies
SYS-1027R-WC1NR
SYS-1027R-WC1NR

/ SYS-1027R-WC1NRT

2 NVMe PCIe SSD/SATA3
  • Dual Socket R (LGA 2011) support Intel® Xeon® processor E5-2600 or E5-2600 v2 family
  • 2 NVMe and 8x 2.5" Hot-swap SAS3 drives; Broadcom 3108 SAS3; RAID 0, 1, 5, 6, 10, 50, 60
  • 16 DIMM slots: up to 1TB ECC DDR3, up to 1866MHz memory
  • 1 PCI-E 3.0 x16 Full-height, Half-length slot
  • Connectivity: 2 GbE (-WC1NR) / 2x 10GBase-T (-WC1NRT)
  • System management: Built-in Server management tool (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
  • 5x 40x56mm counter-rotating PWM fans
  • 700W Redundant Gold Level Power Supplies
Global SKU
