Supermicro MicroCloud Solutions

Up to 24 Modular UP Server Nodes in 3U

The Supermicro MicroCloud modular server system provides the high density, high performance, high efficiency and cost effectiveness required for cloud computing infrastructure. Up to 24 server systems (nodes) are conveniently integrated into a compact 3U chassis that is only 23 inches deep. The Supermicro MicroCloud systems are optimized for cloud computing providers, data and web hosting, HPC, data centers, compute intensive applications, virtualization, and data farms.


  • Cloud Computing, Web Cache, Web Hosting, VM, Social Networking, Corporate-WINS
  • Single socket H4 (LGA 1151) supports Intel® Xeon® Processor E-2100 series, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C246 chipset
  • Up to 128GB unbuffered ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots
  • 2x 1GbE LAN ports (Intel i350)
  • 1 Micro-LP slot (MicroLP upgradable)
  • Drive options: 2x 3.5" SATA3 or 4x 2.5" SATA3 drives or
  • 2x 2.5" NVMe + 2x 2.5" SATA3 drives or 2x 2.5" NVMe + 1x 3.5" SATA3 drive
  • M.2: 1 PCI-E 3.0 x4, 2280/22110, M-Key
  • 1 VGA port, 1 TPM 2.0 (header)
  • 4x 9cm Heavy duty fans with optimal cooling zone (per system)
  • 2000W Redundant Titanium Level power supplies

  • Cloud Computing, Web Cache, Web Hosting, VM, Social Networking, Corporate-WINS
  • Single socket H4 (LGA 1151) supports Intel® Xeon® Processor E-2100 series, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C246 chipset
  • Up to 128GB unbuffered ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots
  • 2x 1GbE LAN ports (Intel i350)
  • 1 PCI-E 3.0 LP slot, 1 Micro-LP slot (MicroLP upgradable)
  • Drive options: 2x 3.5" SATA3 or 2x 2.5" SATA3 drives (with optional kits)
  • M.2: 2 PCI-E 3.0 x4, 2280/22110, M-Key
  • 1 VGA port, 1 TPM 2.0 (header)
  • 4x 8cm Heavy duty fans with optimal cooling zone (per system)
  • 2000W Redundant Titanium Level power supplies
  • Cloud computing, dynamic web serving, dedicated hosting, content delivery network, memory caching, and corporate applications
  • 8 modular UP Nodes in 3U; EACH NODE:
  • Intel® Xeon® processor D-2141i SoC, 8-Cores, 16 Threads, 65W
  • Up to 512GB ECC LRDIMM, up to 256GB ECC RDIMM DDR4-2133MHz in 4 DIMM slots
  • 2 GbE LAN ports and 1 dedicated LAN supports IPMI 2.0
  • 2x 3.5" SATA3 or 2x 2.5" Hybrid SATA3/NVMe w/ optional kits
  • 1 PCI-E 3.0 x16, 1 Micro-LP, and 2 M.2
  • 1600W Redundant Titanium Level Power Supplies
  • Cloud computing, dynamic web serving, dedicated hosting, content delivery network, memory caching, and corporate applications
  • 8 modular UP Nodes in 3U; EACH NODE:
  • Intel® Xeon® processor D-2191 SoC, 18-Cores, 36 Threads, 86W
  • Up to 512GB ECC LRDIMM, up to 256GB ECC RDIMM DDR4-2400MHz in 4 DIMM slots
  • 2 GbE LAN ports and 1 dedicated LAN supports IPMI 2.0
  • 2x 3.5" SATA3 or 2x 2.5" Hybrid SATA3/NVMe w/ optional kits
  • 1 PCI-E 3.0 x16, 1 Micro-LP, and 2 M.2
  • 1600W Redundant Titanium Level Power Supplies
  • 12 modular UP Nodes in 3U; EACH NODE:
  • Intel® Atom® processor C3955; Socket FCBGA1310
  • Intel® C3000 chipset
  • Up to 128GB RDIMM or 64GB UDIMM,
    up to 2400MHz DDR4 VLP ECC memory support
  • Flexible storage options: 2x 3.5" SATA3 or 4x 2.5" SATA3 or
    2x 2.5" NVMe + 2x 2.5" SATA3 or 2x 2.5" NVMe + 1x 3.5" SATA3
  • 2x 10GBase-T LAN ports via C3000 SoC
  • 4 heavy-duty 9cm PWM fans with optimal cooling zone
  • 2000W Redundant Titanium Level Power Supplies
  • 12 modular UP Nodes in 3U; EACH NODE:
  • Intel® Atom® processor C3750; Socket FCBGA1310
  • Intel® C3000 chipset
  • Up to 128GB RDIMM or 64GB UDIMM,
    up to 2400MHz DDR4 VLP ECC memory support
  • Flexible storage options: 2x 3.5" SATA3 or 4x 2.5" SATA3 or
    2x 2.5" NVMe + 2x 2.5" SATA3 or 2x 2.5" NVMe + 1x 3.5" SATA3
  • 2x 10GBase-T LAN ports via C3000 SoC
  • 4 heavy-duty 9cm PWM fans with optimal cooling zone
  • 2000W Redundant Titanium Level Power Supplies
  • 8 modular UP Nodes in 3U; EACH NODE:
  • Intel® Xeon® processor E3-1200 v6/v5 family; socket H4 (LGA 1151)
  • Intel® C236 chipset
  • Up to 64GB UDIMM, up to 2400MHz DDR4 ECC memory support
  • 2x 3.5" SATA3 (default) or 2x 2.5" SATA3 HDDs with optional kits
  • 2 GbE LAN ports and 1 dedicated LAN supports IPMI 2.0
  • 2 USB 2.0, 1 VGA, 1 COM port (w/ KVM dongle), 1 SATA DOM
  • 1 PCI-E 3.0 x8 and 1 Micro-LP
  • 4x 8cm heavy-duty PWM fans with optimal cooling zone
  • 1600W Redundant Titanium Level Power Supplies
  • 12 modular UP Nodes in 3U; EACH NODE:
  • Intel® Xeon® processor E3-1200 v6/v5 family; socket H4 (LGA 1151)
  • Intel® C236 chipset
  • Up to 64GB UDIMM, up to 2400MHz DDR4 VLP ECC memory support
  • Flexible storage options: 2x 3.5" SATA3 or 4x 2.5" SATA3 or 2x 2.5" NVMe + 2x 2.5" SATA3 or 2x 2.5" NVMe + 1x 3.5" SATA3
  • 2 GbE LAN ports and 1 dedicated LAN supports IPMI 2.0
  • 2 USB 2.0, 1 VGA, 1 COM port (w/ KVM dongle); 1 USB 3.0 (Type A), 1 SATA DOM
  • 1 Micro-LP
  • 4x 9cm heavy-duty PWM fans with optimal cooling zone
  • 2000W Redundant Titanium Level Power Supplies
  • 12 trays per system, 2 modular UP Nodes per tray in 3U, EACH NODE:
  • Intel® Xeon® processor D-1531 SoC, 6-Core, 45W
  • Up to 128GB ECC DDR4 RDIMM 2133MHz in 4 DIMM slots
  • 1x 2.5" SATA3 HDDs; optional kit for 2x 2.5" slim SSDs
  • 2 GbE LAN ports, 1 shared LAN port for IPMI Remote Management
  • 2 USB 2.0, 1 VGA, 1 COM port (w/ KVM dongle)
  • 4x 9cm heavy-duty PWM fans with optimal cooling zone
  • 1600W Redundant Platinum Level Power Supplies
  • Cloud and Virtualization, Computing, Web Servers
  • 8 modular UP Nodes in 3U; EACH NODE:
  • Intel® Xeon® processor D-1541 SoC, 8 cores, 45W
  • Up to 128GB ECC DDR4 RDIMM 2133MHz in 4 DIMM slots
  • 2 GbE LAN ports and 1 dedicated LAN supports IPMI 2.0
  • 2x 3.5" Hot-swap SATA3/SAS Drive Bays
  • 1 PCI-E 3.0 x8 (LP) slot, MicroLP slot, 4 M Key 2242/22110
  • 1600W Redundant Titanium Level Power Supplies
  • 8 modular UP Nodes in 3U; EACH NODE:
  • Intel® Xeon® processor E5-2600 v4/v3 family; socket R3 (LGA 2011)
  • Intel® C612 chipset
  • Up to 512GB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz in 4 DIMM slots
  • 2x 3.5" Hot-swap SATA3/SAS drive bays
  • 2 GbE LAN ports and 1 dedicated LAN supports IPMI 2.0
  • 2 USB 2.0, 1 VGA, 1 COM port (w/ KVM dongle), 1 SATA DOM
  • 1 PCI-E 3.0 x8 Low-profile expansion slot
  • 4 heavy-duty 8cm PWM fans with optimal cooling zone
  • 1620W Redundant Platinum Level Power Supplies
  • 12 trays per system, 2 modular UP Nodes per tray in 3U, EACH NODE:
  • Intel® Atom processor C2750 SoC, FCBGA 1283, 20W 8-Core
  • Up to 64GB DDR3 VLP ECC UDIMM 1600MHz memory support
  • 2x 2.5" SATA3 HDDs
  • 2 GbE LAN ports, shared LAN supports IPMI 2.0
  • 2 USB 2.0 ports, 1 VGA
  • 4 heavy-duty 9cm PWM fans with optimal cooling zone
  • 1620W Redundant Platinum Level Power Supplies
  • 12 trays per system, 2 modular UP Nodes per tray in 3U, EACH NODE:
  • Intel® Xeon® processor E3-1200 v3 family, Intel® 4th/5th Gen Core™ processor family; socket H3 (LGA 1150) up to 80W
  • Intel® C224 PCH Chipset
  • Up to 32GB DDR3 VLP ECC UDIMM 1600/1333MHz memory support
  • 1x 2.5" SATA3 HDD; optional kit for 2x 2.5" slim SSDs
  • 4 GbE LAN ports and 1 dedicated LAN supports IPMI 2.0
  • 2 USB 2.0 ports, 1 VGA
  • 4 heavy-duty 9cm PWM fans with optimal cooling zone
  • 2000W Redundant Platinum Level Power Supplies
  • 12 modular UP Nodes in 3U, EACH NODE:
  • Intel® Xeon® processor E3-1200 v3/v4 family, Intel® 4th/5th Gen Core™ processor family; socket H3 (LGA 1150) from 13W to 80W
  • Intel® C224 PCH Chipset
  • Up to 32GB DDR3 VLP ECC UDIMM 1600/1333MHz memory support
  • 2x 3.5" SATA3 HDDs; optional kit for 4x 2.5" SATA HDDs
  • 2 GbE LAN ports and 1 dedicated LAN supports IPMI 2.0
  • 2 USB 2.0 ports, 1 VGA, 1 USB 3.0 (Type-A), 1 SATA DOM
  • 4 heavy-duty 9cm PWM fans with optimal cooling zone
  • 1620W Redundant Platinum Level Power Supplies
  • 8 modular UP Nodes in 3U; EACH NODE:
  • Intel® Xeon® processor E3-1200 v3/v4 family, Intel® 4th/5th Gen Core™ processor family; socket H3 (LGA 1150) from 13W to 84W
  • Intel® C224 PCH chipset
  • Up to 32GB DDR3 ECC UDIMM 1600/1333MHz memory support
  • 2x 3.5" hot-swap SAS/SATA HDDs (SW/HW RAID 0,1 depends on RAID card config.)
  • 2 GbE LAN ports and 1 dedicated LAN supports IPMI 2.0
  • 2 USB 2.0 ports, 1 USB 3.0 (Type-A), 1 VGA, 1 SATA DOM
  • Low-profile PCI-E x8 expansion support
  • 4 heavy-duty 8cm PWM fans with optimal cooling zone
  • 1620W Redundant Platinum Level Power Supplies
