Generation
X12
X12
X12
# of CPU Sockets
Single
Single
Single
CPU Type Supported
  • Intel® Xeon® Processor D-1718T
  • Single Socket FCBGA-2227 supported, CPU TDP support Up to 46W TDP
  • Intel® Xeon® Processor D-1736NT
  • Single Socket FCBGA-2227 supported, CPU TDP support Up to 67W TDP
  • Intel® Xeon® Processor D-1749NT
  • Single Socket FCBGA-2227 supported, CPU TDP support Up to 80W TDP
Memory Capacity
  • Up to 128GB ECC RDIMM, DDR4 -2933MHz, Up to 128GB ECC/non-ECC UDIMM, DDR4 -2933MHz, in2 DIMM slots
  • Up to 128GB ECC RDIMM, DDR4 -2933MHz, Up to 128GB ECC/non-ECC UDIMM, DDR4 -2933MHz, in2 DIMM slots
  • Up to 128GB ECC RDIMM, DDR4 -2933MHz, Up to 128GB ECC/non-ECC UDIMM, DDR4 -2933MHz, in2 DIMM slots
Memory Type
  • 2933/2666/2400MHz ECC DDR4
  • 2933/2666/2400MHz ECC DDR4
  • 2933/2666/2400MHz ECC DDR4
Form Factor
Mini-ITX 6.75" x 6.75"
Mini-ITX 6.75" x 6.75"
Mini-ITX 6.75" x 6.75"
Chipset
System on Chip
System on Chip
System on Chip
# of System Memory Slots
2
2
2
Onboard Storage Controller
  • SoC controller for 4 SATA3 (6 Gbps) ports; RAID 0,1,5,10
  • 4 SATA ports via OCuLink (or PCIE3.0 x4 for NVMe)
  • SoC controller for 4 SATA3 (6 Gbps) ports; RAID 0,1,5,10
  • 4 SATA ports via OCuLink (or PCIE3.0 x4 for NVMe)
  • SoC controller for 4 SATA3 (6 Gbps) ports; RAID 0,1,5,10
  • 4 SATA ports via OCuLink (or PCIE3.0 x4 for NVMe)
Expansion Slot
  • 1 PCI-E 4.0 x8
  • 1 PCI-E 3.0 x4 (or 4x SATA), via Oculink
  • 1 PCI-E 3.0 NVMe x4 OCuLink  Internal  Port(s)
  • M.2 Interface: 1 SATA/PCI-E 4.0 x4
  • M.2 Form Factor: 2280
  • M.2 Key: M-Key
  • 1 PCI-E 4.0 x8
  • 1 PCI-E 3.0 x4 (or 4x SATA), via Oculink
  • 1 PCI-E 3.0 NVMe x4 OCuLink  Internal  Port(s)
  • M.2 Interface: 1 SATA/PCI-E 4.0 x4
  • M.2 Form Factor: 2280
  • M.2 Key: M-Key
  • 1 PCI-E 3.0 x4 (or 4x SATA), via Oculink
  • 1 PCI-E 4.0 x8
  • 1 PCI-E 3.0 NVMe x4 OCuLink  Internal  Port(s)
  • M.2 Interface: 1 SATA/PCI-E 4.0 x4
  • M.2 Form Factor: 2280
  • M.2 Key: M-Key
Onboard LAN
N/A
N/A
N/A
USB
  • 2 USB 2 ports (2 via headers)
  • 2 USB 3 ports (2 rear type A)
  • 2 USB 2 ports (2 via headers)
  • 2 USB 3 ports (2 rear type A)
  • 2 USB 2 ports (2 via headers)
  • 2 USB 3 ports (2 rear type A)
Video Output
1 VGA D-Sub Connector port
1 VGA D-Sub Connector port
1 VGA D-Sub Connector port
Other Onboard I/O Devices
  • 1 COM Port (1 header)
  • 1 COM Port (1 header)
  • 1 COM Port (1 header)
TPM Header
Yes
Yes
Yes
Storage Interfaces
  • M.2 Interface: 1 SATA/PCI-E 4.0 x4
  • M.2 Form Factor: 2280
  • M.2 Key: M-Key
  • 1 PCI-E 3.0 NVMe x4 OCuLink  Internal  Port(s)
  • M.2 Interface: 1 SATA/PCI-E 4.0 x4
  • M.2 Form Factor: 2280
  • M.2 Key: M-Key
  • 1 PCI-E 3.0 NVMe x4 OCuLink  Internal  Port(s)
  • M.2 Interface: 1 SATA/PCI-E 4.0 x4
  • M.2 Form Factor: 2280
  • M.2 Key: M-Key
  • 1 PCI-E 3.0 NVMe x4 OCuLink  Internal  Port(s)
