Supermicro Solutions based on Intel® Xeon® E Processors

Supermicro leverages its deep expertise in server technology focused on first-to-market solutions optimized for Intel® Xeon® E-2100 and E-2200 processors with enterprise-class reliability and performance, offering new entry-servers designed to tackle today’s most demanding applications at an affordable price. This broad portfolio of UP systems includes general purpose servers and towers, workload-optimized servers for network appliances and edge applications, as well as blades and multi-node systems for high-density environments.

The new Supermicro Building Block Solutions® for the Intel® Xeon® E-2100 and E-2200 series include new server-class motherboards offering a wide range of high performance, network appliance and embedded/IoT applications.

  • Up to 8-core/16 threads Intel® Xeon® E-2100 and E-2200 processors
  • Up to 128GB DDR4-2666MHz memory
  • Intel® Optane™ Memory support
  • Dual M.2 slots
  • 6U & 3U blade enclosures
  • Up to 8 onboard 1GbE LAN networking
  • Options for NVMe, SATA 3.0, and SAS storage
  • PCI-E 3.0 x16 expansion options

Server / Workstation / IoT Solutions

SYS-5019C-MHN2
SYS-5019C-MHN2
  • General Purpose, SMB, Web Hosting, Application and data serving, Archiving, Mail/Finance, Security
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C246 chipset
  • Up to 128GB unbuffered ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots
  • 2x 1GbE LAN ports (Intel i210-AT)
  • 1 PCI-E 3.0 x16 slot
  • 4 Hot-swap 3.5" drive bays
  • M.2: 1 SATA/PCI-E 3.0 x4 and 1 PCI-E 3.0 x4, 2280/22110, M-Key
  • 2 USB 3.1 ports (rear), 2 USB 2.0 ports (rear)
  • 1 VGA port, 1 COM (header), 1 TPM 2.0 (header)
  • 350W Multi-output Platinum Level power supply
SYS-5019C-M
SYS-5019C-M
  • General Purpose, SMB, Web Hosting, Application and data serving, Archiving, Mail/Finance, Security
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C246 chipset
  • Up to 128GB unbuffered ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots
  • 2x 1GbE LAN ports (Intel i210-AT)
  • 1 PCI-E 3.0 x16 slot
  • 4 Hot-swap 3.5" drive bays
  • M.2: 1 SATA/PCI-E 3.0 x4 and 1 PCI-E 3.0 x4, 2280/22110, M-Key
  • 2 USB 3.1 ports (rear)
  • 1 VGA port, 1 COM (header), 1 TPM 2.0 (header)
  • 350W Multi-output Platinum Level power supply
SYS-5019C-MR
SYS-5019C-MR
  • General Purpose, SMB, Web Hosting, Application and data serving, Archiving, Mail/Finance, Security
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C246 chipset
  • Up to 128GB unbuffered ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots
  • 2x 1GbE LAN ports (Intel i210-AT)
  • 1 PCI-E 3.0 x16 slot
  • 4 Hot-swap 3.5" drive bays
  • M.2: 1 SATA/PCI-E 3.0 x4 and 1 PCI-E 3.0 x4, 2280/22110, M-Key
  • 2 USB 3.1 ports (rear), 2 USB 2.0 (rear)
  • 1 VGA port, 1 COM (header), 1 TPM 2.0 (header)
  • 400W Redundant Platinum Level power supplies
SYS-5019C-WR
SYS-5019C-WR
  • HA, High flexibility, VM, Communication, Application and data serving, Appliance Server
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C246 chipset
  • Up to 128GB unbuffered ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots
  • 2x 1GbE LAN ports (Intel i210-AT)
  • 1 PCI-E 3.0 x16 slot or 2 PCI-E 3.0 x8, 1 PCI-E 3.0 x4 (in x8) slot
  • 4 Hot-swap 3.5" drive bays
  • M.2: 1 SATA/PCI-E 3.0 x4 and 1 PCI-E 3.0 x4, 2260/2280/22110, M-Key
  • 2 USB 3.1 ports (rear), 2 USB 2.0 (rear)
  • 1 VGA port, 2 COM, 1 TPM 2.0 (header)
  • 500W Redundant Platinum Level power supplies
SYS-5019C-M4L
SYS-5019C-M4L
  • Entry level, Cost effective, Compact, less than 15" depth
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C242 chipset
  • Up to 128GB unbuffered ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots
  • 4x 1GbE LAN ports (Intel i210-AT)
  • 1 PCI-E 3.0 x16 slot
  • 2 Fixed 3.5" or 3 Fixed 2.5" drive bays
  • M.2: 1 PCI-E 3.0 x4, 2280/22110, M-Key
  • 2 USB 3.1 ports (rear), 2 USB 2.0 ports (rear)
  • 1 VGA port, 1 COM (header), 1 TPM 2.0 (header)
  • 350W Multi-output Platinum Level power supply
SYS-5019C-FL
SYS-5019C-FL
  • Appliance Server, Security/Gateway Server, Edge Computing
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C242 chipset
  • Up to 64GB unbuffered ECC UDIMM, DDR4-2666MHz, in 2 DIMM slots
  • 2x 1GbE LAN ports (Intel i210-AT)
  • 1 PCI-E 3.0 x16 slot
  • 2 Fixed 3.5" drive bay or 4 Fixed 2.5" drive bays
  • M.2: 1 PCI-E 3.0 x4, 2280, M-Key
  • 2 USB 3.1 ports (front), 2 USB 2.0 ports (front)
  • Front side: 1 VGA port, 2 COM, 1 TPM 2.0 (header)
  • 200W Multi-output Gold Level power supply
SYS-5019C-L
SYS-5019C-L
  • Appliance Server, Front-end, Web Hosting, Edge Computing
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C242 chipset
  • Up to 64GB unbuffered ECC UDIMM, DDR4-2666MHz, in 2 DIMM slots
  • 2x 1GbE LAN ports (Intel i210-AT)
  • 1 PCI-E 3.0 x16 slot
  • 2 Fixed 3.5" drive bay or 4 Fixed 2.5" drive bays
  • M.2: 1 PCI-E 3.0 x4, 2280, M-Key
  • 2 USB 3.1 ports (rear), 2 USB 2.0 ports (rear)
  • 1 VGA port, 2 COM, 1 TPM 2.0 (header)
  • 200W Multi-output Gold Level power supply
SYS-1019C-FHTN8
SYS-1019C-FHTN8
  • uCPE Network Appliance, Network Security Appliance, Virtualization Server
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C246 chipset
  • Up to 128GB unbuffered ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots
  • 8x 1GbE LAN ports (Intel i210-AT)
  • 1 PCI-E 3.0 x16 slot
  • 2 Hot-swap 2.5", 2 Internal 2.5" SATA3 drive bays (SSD only)
  • M.2: 1 SATA/PCI-E 3.0 x4, 2280, M-Key
  • 2 USB 3.1 ports (rear), 2 USB 2.0 ports (rear)
  • 1 VGA port, 1 COM, 1 TPM 2.0 (header)
  • 350W Platinum Level AC-DC multiple output power supply
SYS-5039MC-H12TRF
SYS-5039MC-H12TRF
  • Cloud Computing, Web Cache, Web Hosting, VM, Social Networking, Corporate-WINS
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C246 chipset
  • Up to 128GB unbuffered ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots
  • 2x 1GbE LAN ports (Intel i350)
  • 1 Micro-LP slot (MicroLP upgradable)
  • Drive options: 2x 3.5" SATA3 or 4x 2.5" SATA3 drives or
  • 2x 2.5" NVMe + 2x 2.5" SATA3 drives or 2x 2.5" NVMe + 1x 3.5" SATA3 drive
  • M.2: 1 PCI-E 3.0 x4, 2280/22110, M-Key
  • 1 VGA port, 1 TPM 2.0 (header)
  • 4x 9cm Heavy duty fans with optimal cooling zone (per system)
  • 2000W Redundant Titanium Level power supplies
SYS-5039MC-H8TRF
SYS-5039MC-H8TRF
  • Cloud Computing, Web Cache, Web Hosting, VM, Social Networking, Corporate-WINS
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C246 chipset
  • Up to 128GB unbuffered ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots
  • 2x 1GbE LAN ports (Intel i350)
  • 1 PCI-E 3.0 LP slot, 1 Micro-LP slot (MicroLP upgradable)
  • Drive options: 2x 3.5" SATA3 or 2x 2.5" SATA3 drives (with optional kits)
  • M.2: 2 PCI-E 3.0 x4, 2280/22110, M-Key
  • 1 VGA port, 1 TPM 2.0 (header)
  • 4x 8cm Heavy duty fans with optimal cooling zone (per system)
  • 2000W Redundant Titanium Level power supplies
SYS-5029C-T
SYS-5029C-T
  • File server/ Entry Storage, Local Cloud and Web Hosting, Mainstream
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C242 chipset
  • Up to 64GB unbuffered ECC UDIMM, DDR4-2666MHz, in 2 DIMM slots
  • 2x 1GbE LAN ports (Intel i210-AT)
  • 1 PCI-E 3.0 x16 slot, for low-profile AOC
  • 4 Hot-swap 3.5" drive bays, 2 Fixed 2.5" drive bays
  • 1 M.2 (M-key, 2280) via PCI-E 3.0 x4 or SATA 3.0
  • 2 USB 3.1 Gen1 (front), 2 USB 3.1 Gen1 (rear), 2 USB 2.0 ports (rear)
  • 1 VGA port, 1 COM, 1 TPM 2.0 (header)
  • 250W Bronze Level power supply
SYS-5039C-I
SYS-5039C-I
  • Entry-Level Server for SOHO, SMB, Remote access for mobile users, Data sharing/storage and Centralized backup
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C242 chipset
  • Up to 128GB unbuffered ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots
  • 2x 1GbE LAN ports (Intel i210-AT)
  • 1 PCI-E 3.0 x8 (in x16) slot, 2 PCI-E 3.0 x4 (in x8) slots
  • 4 Fixed 3.5" drive bays, 2 External 5.25" peripheral bays
  • 1 M.2 (M-Key, 22110/2280) via PCI-E 3.0 x4
  • 2 USB 3.1 Gen1 (front), 2 USB 3.1 Gen1 (rear), 2 USB 2.0 (rear)
  • 1 VGA port, 1 COM, 1 TPM 2.0 (header)
  • 400W Gold Level power supply
SYS-5039C-T
SYS-5039C-T
  • Entry-Level Worksation, CAD/CAM/CAE, Digital Imaging, 3D Simulation and Rendering, Cost effective UP platform
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3 processors, Intel® Celeron®, Intel® Pentium®
  • Up to 64GB ECC/non-ECC UDIMM in 4 DIMM slots
  • 2x 1GbE LAN ports (Intel i210-AT and Intel PHY I219LM)
  • 4 Fixed 3.5" and 4 optional 2.5" drive bays, 2 standard 5.25" peripheral drive bays, 1 Internal 3.5" fixed device bay
  • 2 PCI-E 3.0 x16 (NA/16 or 8/8), 1 PCI-E 3.0 x4, 1 PCI-E 3.0 x1, 1 PCI 32bit 5V
  • 2 M.2 (M key, 2260/2280/22110), 1 U.2 for optional expanded storages
  • 2 USB Type A & Type C, 4 USB 3.1 Gen1 (2 rear + 2 front), 2 USB 2.0 (front)
  • 1 HDMI 2.0a port, 1 DVI-D port, 1 DP 1.2 port, 1 TPM header, 1 COM header, 7.1 HD Audio
  • 500W Bronze Certified High Efficient power supply
SYS-1019C-HTN2
SYS-1019C-HTN2
  • Digital Signage, DVR/NVR, POS, Office Server, Security Appliance Network Security, and Video Surveillance
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3 processors, Intel® Celeron®, Intel® Pentium®
  • Up to 64GB unbuffered ECC/non-ECC UDIMM in 4 DIMM slots
  • 2x 1GbE LAN ports (Intel i210-AT and Intel PHY I219LM)
  • 1x 3.5" or 4x 2.5" drive bays with bracket
  • 1x PCI-E 3.0 x8 slot, M.2 PCIe 3.0 x4, M Key 2242/2280/22110
  • Mini-PCIe with mSATA support
  • 4 USB 3.1 (3 Type A, 1 Type C), 1 COM, 1 TPM, 1 HDMI, 1 DVI, ALC 888S HD Audio
  • 400W Redundant Platinum Level Power Supplies
SBI-4119MG-X
SBI-4119MG-X
1-Socket Blade
  • Single Socket H4 (LGA 1151) support: Intel® Xeon® E-2100 and E-2200 processors
  • 100 CPUs per 42U Rack
  • Intel® C246 chipset
  • 4 DIMM slots; up to 128GB ECC UDIMM, up to DDR4 2666MHz
  • Storage: 1 NVMe/SATA3 M.2, 1 SATA DOM
  • Dual 10G onboard
  • IPMI 2.0, KVM over IP, Virtual Media over LAN
  • Graphics: Aspeed AST2500 BMC
  • LED Indicators: Power, UID/KVM, Networking, and Fault LED
  • Dimensions: 6.5" x 1.75" x 23.5"
MBI-6119M-C2
MBI-6119M-C2
  • 196 UP nodes per 42U Rack, 28/14 UP nodes in 6U/3U
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors
  • Intel ® C246 chipset
  • Up to 128GB ECC VLP UDIMM, DDR4-2666MHz, in 4 DIMM slots
  • 2x 1GbE LAN ports
  • 1 PCI-E 3.0 x16 slot, 1 PCI-E 3.0 x4 (in x8) slot
  • M.2: 1 PCI-E 3.0 x4, 2280/22110, M-Key
  • Up to 2x 2.5" SAS3 drives via Avago 3008
  • 1 VGA, 1 SuperDOM
MBI-6119M-T2N
MBI-6119M-T2N
  • 196 UP nodes per 42U Rack, 28/14 UP nodes in 6U/3U
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors
  • Intel ® C246 chipset
  • Up to 128GB ECC VLP UDIMM, DDR4-2666MHz, in 4 DIMM slots
  • 2x 1GbE LAN ports
  • 1 PCI-E 3.0 x16 slot, 1 PCI-E 3.0 x4 (in x8) slot
  • M.2: 1 PCI-E 3.0 x4, 2280/22110, M-Key
  • Up to 2x 2.5" NVMe/SATA3 drives
  • 1 VGA, 1 SuperDOM
X11SCW-F
X11SCW-F
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C246 chipset
  • Up to 128GB unbuffered ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots
  • 2x 1GbE LAN ports (Intel i210-AT)
  • 1 PCI-E 3.0 x16 slot, 1 PCI-E 3.0 x4 (in x8) slot
  • M.2: 1 SATA/PCI-E 3.0 x4 and 1 PCI-E 3.0 x4, 2260/2280/22110, M-Key
  • Up to 6 SATA3 (6Gbps) ports; RAID 0, 1, 5, 10
  • 4 USB 3.1 Gen2 (2 header, 2 rear), 1 USB 3.1 Gen1 (Type A), 6 USB 2.0
  • 1 VGA, 2 COM, 1 TPM header, 2 SuperDOM
  • Form factor: Proprietary WIO, 8" x 13"
X11SCM-F
X11SCM-F
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C246 chipset
  • Up to 128GB unbuffered ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots
  • 2x 1GbE LAN ports (Intel i210-AT)
  • 1 PCI-E 3.0 x16 slot
  • M.2: 1 SATA/PCI-E 3.0 x4 and 1 PCI-E 3.0 x4, 2280/22110, M-Key
  • Up to 6 SATA3 (6Gbps) ports; RAID 0, 1, 5, 10
  • 5 USB 3.1 Gen1 (2 rear, 2 header, 1 Type A), 4 USB 2.0 (2 rear, 2 header)
  • 1 VGA, 1 COM, 1 TPM header, 2 SuperDOM
  • Form factor: micro ATX, 9.6" x 9.6"
X11SCM-LN8F
X11SCM-LN8F
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C246 chipset
  • Up to 128GB unbuffered ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots
  • 8x 1GbE LAN ports (Intel i210-AT)
  • 1 PCI-E 3.0 x16 slot
  • M.2: 1 SATA/PCI-E 3.0 x4 and 1 PCI-E 3.0 x4, 2280/22110, M-Key
  • Up to 6 SATA3 (6Gbps) ports; RAID 0, 1, 5, 10
  • 5 USB 3.1 Gen1 (2 rear, 2 header, 1 Type A), 4 USB 2.0 (2 rear, 2 header)
  • 1 VGA, 1 COM, 1 TPM header, 2 SuperDOM
  • Form factor: micro ATX, 9.6" x 9.6"
X11SCL-LN4F
X11SCL-LN4F
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C242 chipset
  • Up to 128GB unbuffered ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots
  • 4x 1GbE LAN ports (Intel i210-AT)
  • 1 PCI-E 3.0 x16 slot
  • M.2: 1 PCI-E 3.0 x4, 2280/22110, M-Key
  • Up to 6 SATA3 (6Gbps) ports; RAID 0, 1, 5, 10
  • 5 USB 3.1 Gen1 (2 rear, 2 header, 1 Type A), 4 USB 2.0 (2 rear, 2 header)
  • 1 VGA, 1 COM, 1 TPM header, 2 SuperDOM
  • Form factor: micro ATX, 9.6" x 9.6"
X11SCL-F
X11SCL-F
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C242 chipset
  • Up to 128GB unbuffered ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots
  • 2x 1GbE LAN ports (Intel i210-AT)
  • 1 PCI-E 3.0 x8 (in x16) slot, 2 PCI-E 3.0 x4 (in x8) slots
  • M.2: 1 PCI-E 3.0 x4, 2280/22110, M-Key
  • Up to 6 SATA3 (6Gbps) ports; RAID 0, 1, 5, 10
  • 5 USB 3.1 Gen1 (2 rear, 2 header, 1 Type A), 6 USB 2.0 (2 rear, 4 header)
  • 1 VGA, 2 COM, 1 TPM header, 2 SuperDOM
  • Form factor: micro ATX, 9.6" x 9.6"
X11SCL-IF
X11SCL-IF
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C242 chipset
  • Up to 64GB unbuffered ECC UDIMM, DDR4-2666MHz, in 2 DIMM slots
  • 2x 1GbE LAN ports (Intel i210-AT)
  • 1 PCI-E 3.0 x16 slot
  • M.2: 1 PCI-E 3.0 x4, 2280, M-Key
  • Up to 4 SATA3 (6Gbps) ports; RAID 0, 1, 5, 10
  • 5 USB 3.1 Gen1 (2 rear, 2 header, 1 Type A), 4 USB 2.0 (2 rear, 2 header)
  • 1 VGA, 1 COM, 1 TPM header, 2 SuperDOM
  • Form factor: mini-ITX, 6.7" x 6.7"
X11SCH-F
X11SCH-F
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C246 chipset
  • Up to 128GB unbuffered ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots
  • 2x 1GbE LAN ports (Intel i210-AT)
  • 1 PCI-E 3.0 x8 (in x16) slot, 1 PCI-E 3.0 x8 slot
  • M.2: 2 PCI-E 3.0 x4, 2280/22110, M-Key
  • Up to 8 SATA3 (6Gbps) ports; RAID 0, 1, 5, 10
  • 2 USB 3.1 Gen2 (rear), 3 USB 3.1 Gen1 (2 header, 1 Type A), 6 USB 2.0 (2 rear, 4 headers)
  • 1 VGA, 2 COM, 1 TPM header, 2 SuperDOM
  • Form factor: Micro-ATX, 9.6" x 9.6"
X11SCH-LN4F
X11SCH-LN4F
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3/Pentium®/Celeron®; Intel ® C246 chipset
  • Up to 128GB unbuffered ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots
  • 4x 1GbE LAN ports (Intel i210-AT)
  • 1 PCI-E 3.0 x8 (in x16) slot, 1 PCI-E 3.0 x8 slot
  • M.2: 2 PCI-E 3.0 x4, 2280/22110, M-Key
  • Up to 8 SATA3 (6Gbps) ports; RAID 0, 1, 5, 10
  • 2 USB 3.1 Gen2 (rear), 3 USB 3.1 Gen1 (2 header, 1 Type A), 6 USB 2.0 (2 rear, 4 headers)
  • 1 VGA, 2 COM, 1 TPM header, 2 SuperDOM
  • Form factor: Micro-ATX, 9.6" x 9.6"
X11SCA
X11SCA
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3 processors, Intel® Celeron®, Intel® Pentium®
  • Up to 64GB unbuffered ECC/non-ECC UDIMM in 4 DIMM slots
  • 2x 1GbE LAN ports (Intel i210-AT and Intel PHY I219LM)
  • 1 PCI-E 3.0 x8 slot
  • M.2: 2 PCI-E 3.0 x4, M-Key, 2260/2280/22110 (RAID 0,1); U.2: 1 PCI-E 3.0 x4
  • Up to 8 SATA3 (6Gbps) ports; RAID 0, 1, 5, 10
  • 4 USB 3.1 Gen2 (2 rear + Type A + Type C header), 4 USB 3.1 Gen1 (2 rear + header), 2 USB 2.0 (header)
  • 1 HDMI 2.0, 1 DisplayPort 1.2, 1 DVI-I, 1 TPM header, 1 COM
  • Form factor: ATX, 12" x 9.6"
X11SCA-F
X11SCA-F
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3 processors, Intel® Celeron®, Intel® Pentium®
  • Up to 64GB unbuffered ECC/non-ECC UDIMM in 4 DIMM slots
  • 2x 1GbE LAN ports (Intel i210-AT and Intel PHY I219LM); shared with IPMI
  • 1 PCI-E 3.0 x8 slot
  • M.2: 2 PCI-E 3.0 x4, M-Key, 2260/2280/22110 (RAID 0,1); U.2: 1 PCI-E 3.0 x4
  • Up to 8 SATA3 (6Gbps) ports; RAID 0, 1, 5, 10
  • 4 USB 3.1 Gen2 (2 rear + Type A + Type C header), 4 USB 3.1 Gen1 (2 rear + header), 2 USB 2.0 (header)
  • 1 HDMI 2.0, 1 DisplayPort 1.2, 1 DVI-I, 1 VGA via IPMI, 1 TPM header, 1 COM
  • Form factor: ATX, 12" x 9.6"
X11SCA-W
X11SCA-W
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3 processors, Intel® Celeron®, Intel® Pentium®
  • Up to 64GB unbuffered ECC/non-ECC UDIMM in 4 DIMM slots
  • 2x 1GbE LAN ports (Intel i210-AT and Intel PHY I219LM)
  • 1 PCI-E 3.0 x8 slot
  • M.2: 2 PCI-E 3.0 x4, M-Key, 2260/2280/22110 (RAID 0,1); U.2: 1 PCI-E 3.0 x4
  • Up to 8 SATA3 (6Gbps) ports; RAID 0, 1, 5, 10
  • 4 USB 3.1 Gen2 (2 rear + Type A + Type C header), 4 USB 3.1 Gen1 (2 rear + header), 2 USB 2.0 (header)
  • 1 HDMI 2.0, 1 DisplayPort 1.2, 1 DVI-I, 1 TPM header, 1 COM
  • Gigabit wireless 802.11ac with Bluetooth 5.0
  • Form factor: ATX, 12" x 9.6"
X11SCZ-F
X11SCZ-F
  • Single socket H4 (LGA 1151) supports Intel® Xeon® E-2100 and E-2200 processors, 8th Gen. Intel® Core™ i3 processors, Intel® Celeron®, Intel® Pentium®
  • Up to 64GB unbuffered ECC/non-ECC UDIMM in 4 DIMM slots
  • 2x 1GbE LAN ports (Intel i210-AT and Intel PHY I219LM)
  • 1 PCI-E 3.0 x16, 2 PCI-E 3.0 x4; M.2: 1 M-Key 2280/110, supports PCI-E 3.0 x4/SATA
  • Up to 5 SATA3 (6Gbps) ports; RAID 0, 1, 5, 10
  • 6 USB 3.1 Gen 2 (4 rear + headers), 2 USB 3.1 Gen 1 (headers), 7 USB 2.0 (1 Type A + headers)
  • 2 DP (DisplayPort), 1 DVI-I port, 1 VGA port, HD Audio, onboard TPM2.0, 1 TPM header, 4 COM
  • 12V DC or ATX power input
  • Form factor: Micro ATX, 9.6" x 9.6"
Global SKU
