Key Features
|
|
|
Motherboard (for CSE-826BE1C-R920WB) | ||||
Motherboard Name | ||||
|
||||
= Most optimized Chassis for SuperServer Configuration
Blue color = Compatible Green color = Global SKU & Compatible Red dot & green color = Optimized + Global SKU |
Documentation |
Standard Parts List | |||
Part Number | Qty | Description | |
Air Shroud | MCP-310-29001-0N | 1 | SC825/826/216/213 Intel DP X9,X8 air shroud 13.68x13/12x13 |
Bracket | MCP-320-82601-0N | 1 | Middle fan bracket for 826B/216B with 3 X 8cm fan |
HD Backplane | BPN-SAS3-826EL1 | 1 | SAS 12G Single Expander, LSISAS3x28, Support 12x 3.5" Drives |
Cable(s) | CBL-0071L | 1 | ROUND 16 TO 16 PIN RIBBON FP CABLE 30"L, LF |
Cable(s) | CBL-0160L | 2 | US POWER CORD 16AWG, PB FREE |
Cable(s) | CBL-0182L | 1 | PWR EXTENSION.HDD TO RIGHT ANGLE HDD,PBF |
Cable(s) | CBL-PWEX-1069 | 3 | PWEX,FAN,1X4/P2.5 TO 1X4/P2.54,30CM,22AWG,5A/pin,RoHS |
Part(s) | MCP-230-82603-0N | 1 | Top cover for SC826B, 216B WIO/UIO w/ FH-AOC mylar |
Part(s) | MCP-240-00103-0N | 1 | 2U WIO riser card bracket for SC825, SC826, SC213, SC216 |
Part(s) | MCP-290-00088-0N | 1 | SC119 Intrusion assembly |
Part(s) | MCP-290-82605-0V | 1 | 826 handle |
Part(s) | MCP-290-82606-0N | 1 | SC826 HDD Backplane Bracket |
Fan(s) | FAN-0126L4 | 3 | 80x80x38 mm 7K RPM Chassis Middle Fan w/ Housing |
Front Panel | FPB-TB826 | 1 | 16 pin Cable Adaptor Board for SC826 |
Drive Tray(s) | MCP-220-00075-0B | 12 | Black gen 5.5 hot-swap 3.5" HDD tray |
Drive Tray(s) | MCP-290-82607-0N | 1 | 826B/216B rear dummy cover for 2 X 2.5" HDD cage,RoHS |
Power Distributor | PDB-PT826-S8824 | 1 | PDB with shorter 24pin and 8pin cables for SC826B |
Power Supply & Accessory | PWS-920P-SQ | 2 | 920W 1U Redundant PWS W/ Quiet Mode |
Mounting Rail(s) | MCP-410-00007-0N | 1 | Rail screw bag |
Mounting Rail(s) | MCP-290-00053-0N | 1 | Rail set, quick/quick, default for 2,3U 17.2"W |
Mounting Rail(s) | MCP-290-00060-0N | 1 | Threaded rail adapter default for round hole rack |
Rear Window | MCP-240-82609-0N | 1 | SC826B, 216B WIO rear window |
Optional Parts | |||
Part Number | Qty | Description | |
Front Bezel | MCP-210-82601-0B | - | Black Front Bezel for 826 chassis |
HDD Kit | MCP-220-82609-0N | - | Rear 2.5 x 2 Hot swap HDD kit for 216B/826B/417B/846X/847B |
MCP-220-82616-0N • | - | 12G 2.5x2 Drive Kit w/ Status LED (216B/826B/417B/846X/847B | |
HDD Tray Converter | MCP-220-00118-0B • | - | Black gen-5.5 tool-less 3.5-to-2.5 converter drive tray,RoHS/REACH |
Short Rail | MCP-290-00058-0N • | - | Short rail set, quick release, 19.6"~26.9" Extendable Length |
Tray(s) | MCP-220-00043-0N • | - | Black hotswap gen 4 3.5 to 2.5 HDD tray |
Servers (for CSE-826BE1C-R920WB) | ||||
SSG-6027R-EDT+ | ||||
