C7X99-OCE-F

Key Features

1. Intel® Core™ i7 Processor (Socket R3), Intel® Core™ i7 Processor Extreme Edition (Socket R3), Intel® Xeon® Processor E5-1600 v3, Intel® Xeon® Processor E5-1600 v4, Intel® Xeon® processor E5-2600 v3, Intel® Xeon® processor E5-2600 v4. , Socket R3 (LGA 2011) supported, CPU TDP support Up to 150W TDP
2. 4 PCIe 3.0 x16
   2 PCIe 2.0 x1 (in x4 slot),
   ***4 PCIe3.0x16 slots are running at 16/16/NA/8 or 16/8/8/8***

   ***PCIe slot #1 supports (x4) and slot #4 (x16) is disabled when Intel Core i7-5820K , i7-6800K or any processors with only 28 lanes is installed***
3. Dual LAN with Intel® Ethernet Controller I210-AT
4. Intel® X99
5. Up to 128GB Unbuffered non-ECC UDIMM, DDR4-3300MHz (OC), in 8 DIMM slots
   ***Memory overclocking is not warranty, it is up to the capability of CPU and memory***
6. Intel® X99 controller for 6 SATA3 (6 Gbps) ports; RAID 0,1,5,10
   (I-SATA port#0~5)
   Intel® X99 controller for 4 SATA3 (6 Gbps) ports;
   (s-SATA Port#0~3 don't support Raid)
7. 1 VGA port,
   ***VGA connector is for IPMI only. ***
