Supermicro 2U Twin²® Solutions

The 2U Twin²® extends Supermicro's innovative Twin architecture with hot-swappable compute nodes in space-efficient form factors to facilitate ease of maintenance, reduce/eliminate down time, while saving power and space by sharing the same chassis and power supplies. The 2U Twin² model is optimized for space efficiency and performance-per-watt, featuring four hot-swappable 1U compute nodes in a 2U form factor, each with up to six hot-swap 2.5" SAS2/SATA3 drive bays for exceptional storage capacity. The 2U Twin² also offers one x16 native PCI-Express 3.0 slot for highest non-blocking I/O bandwidth, 8 DIMM slots per node for up to 1TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz memory, onboard Gigabit Ethernet or Mellanox® ConnectX3 single-port 56Gbps InfiniBand to provide greatest networking connectivity, and redundant 1600-watt Titanium Level (96%+) power supplies for greatest efficiency.

The 2U Twin² is designed to further satisfy the ever-increasing efficiency, density, and low-TCO demands of today's High Performance Computing (HPC) clusters, Data Center Web Server and Virtualization, Cloud, and Hyperscale environments.

Add-on Card Compatibility Matrix

Twin²: MicroLP AOC Compatibility Matrix

Resources

Product Brief

Titanium, 96% Efficiency Power Supplies • IB FDR (56Gbps)
  • 4 DP nodes in 2U, depth 28.5", Each Node (x4 nodes):
  • Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family; QPI up to 9.6GT/s
  • 8 DIMM slots; up to 1TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
  • 1 PCI-E 3.0 x16 and 1 PCI-E x8 connectors for SMCI AOC
  • 3x 3.5" Hot-swap SAS2/SATA3 drive bays
  • I/O ports: 2x GbE, 1x Video, 1x RS232, 2x USB 3.0
  • 1 InfiniBand port (FDR, 56Gbps), w/ QSFP connector ('FR' SKU)
  • System management: Built-in Server management tool (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
  • 4 heavy duty fans w/ optimal fan speed control
  • 1600W Redundant Titanium Level (96%) High-efficiency Digital Power Supplies
Titanium, 96% Efficiency Power Supplies • IB FDR (56Gbps)
  • 4 DP nodes in 2U; Each Node (x4 nodes):
  • Dual Socket R3 (LGA 2011) support: Intel® Xeon® processor E5-2600 v4/v3 family; QPI up to 9.6GT/s
  • 6 Hot-swap 2.5" HDD Bays: SATA3 ('HT' SKUs), SAS2 via Broadcom 2208 ('H72' SKUs)
  • 8 DIMM slots; up to 1TB ECC 3DS LRDIMM or RDIMM DDR4-2400MHz
  • 1 PCI-E 3.0 x16 Low-profile slot
  • I/O ports: 2 GbE, 1 Video, 2 USB 3.0 (rear)
  • System management: Built-in Server management tool (IPMI 2.0, KVM/media over LAN) with dedicated LAN port
  • Mellanox ConnectX-3 FDR ('FR' SKUs) IB Controller
  • 4 heavy duty fans w/ optimal fan speed control
  • 1600W Redundant Titanium Level (96%) High-efficiency Digital Power Supplies
