Supermicro Intelligent Management
On-board BMC Specification: [ Click to Show Features ]
| Feature | Supermicro IPMI |
|---|---|
| Interfaces/Connectivity | |
| IPMI 2.0 | ✔ |
| Redfish APIs | ✔ |
| BMC Web GUI | ✔ |
| SMASH-CLP | ✔ |
| DCMI 1.5 | ✔ |
| Serial Redirection | ✔ |
| Dedicated & Shared NIC | ✔ |
| VLAN | ✔ |
| IPv4 & IPv6 | ✔ |
| DHCP | ✔ |
| Dynamic DNS | ✔ |
| SNMP 3.0 | ✔ |
| Directory Services (AD, LDAP, RADIUS) | ✔ |
| Security | |
| Hardware Root of Trust (RoT) | X12/X13 and H12/H13 |
| Signed BMC/BIOS images | ✔ |
| Unique pre-programmed default password | X12/X13 and H12/H13 |
| User account management and Role-based authority | ✔ |
| IP Access Control | ✔ |
| Port Configuration | ✔ |
| UEFI Secureboot | X12/X13 and H12/H13 |
| System Lock down | ✔ |
| Disk secure erase of internal storage devices | ✔ |
| Remote Presence | |
| Remote KVM (graphics) console | ✔ |
| Virtual Media | ✔ |
| Power control | ✔ |
| Boot configuration | ✔ |
| Serial-over-LAN | ✔ |
| Power & Thermal | |
| Temperature monitoring | ✔ |
| Real-time power reading | ✔ |
| Power thresholds & alerts | ✔ |
| Real-time power graphing | ✔ |
| Historical power values | ✔ |
| Power Capping | ✔ |
| System Management & Health Monitoring | |
| Remote agent-free out of band FW updates | ✔ |
| Inband FW Updates | ✔ |
| Component FW Update | ✔ |
| System Component Inventory | ✔ |
| BMS/BIOS/Component configurations | ✔ |
| Fan monitoring | ✔ |
| Power Supply monitoring | ✔ |
| Memory monitoring | ✔ |
| CPU monitoring | ✔ |
| RAID monitoring and configuration | ✔ |
| Intel VROC monitoring and configuration | X12 only |
| GPU monitoring | ✔ |
| NIC monitoring | ✔ |
| HDD monitoring | ✔ |
| Diagnostics, Troubleshooting & Logging | |
| Crash Dump | X12/X13 only |
| Health /System Events | ✔ |
| Events acknowledgement | ✔ |
| Crash screen capture | X12/X13 and H12/H13 |
| Crash video capture | X12/X13 and H12/H13 |
| Syslog | ✔ |
| Post Snooping | ✔ |
The Supermicro X14/H14/X13/H13/X12/H12 platform's BMC (Baseboard Management Controller) is built on the ASPEED AST 2600. AST2600’s design is specifically based on Dual-core ARM Cortex A7 and various hardware interfaces including as Root of Trust (RoT), MCTP over PCIe, and dual JTAG master, supporting modern remote manageability on Supermicro platforms.
The Supermicro X11/H11/H12 platform's BMC is built on ASPEED AST 2500. AST2500’s design is specifically based on ARM11 and various hardware interfaces including PCIe gen 2, PECI 4.0, eSPI, and JTAG master.
The Supermicro X10 platform's BMC is built on the ASPEED AST 2400. The AST2400 design is specifically based on ARM9 and various hardware interfaces including PCIe gen 1, PECI 3.1, and 14 sets of multi-function I2C/SMBus.
| Motherboard | X14/H14 | X13/H13 | X12/H12 | X11/H11/H12 | X10 |
|---|---|---|---|---|---|
| BMC Model | Aspeed AST2600 | Aspeed AST2600 | Aspeed AST2600 | Aspeed AST2500 | Aspeed AST2400 |
| BMC VGA | 1920 x 1200 | 1920 x 1200 | 1920 x 1200 | 1920 x 1200 | 1920 x 1200 |
| BMC Memory | 4G DDR4 | 4G DDR4 | 2G DDR4 | 1G DDR4 | 1G DDR3 |
| BMC Ethernet | 1G | 1G | 1G | 1G | 1G |
BMCs are ideal for server management and support:
- 2D/VGA-compatible graphics
- Multimedia virtualization and Keyboard/Video/Mouse (KVM) redirection functions
- Network access via an external Ethernet PHY module or shared NCSI connections
For configuring BMC securely in data centers, please review our best practices guide.
Supermicro BMC firmware is feature-rich and supports:
- IPMI 2.0 based management
- BMC stack with a full IPMI 2.0 implementation
- Hardware health monitor
- Remote power control
- Redfish based management
- Comprehensive schema and property implementation
- System health monitoring and management
- Various component health monitoring and management
- Network AOC
- Storage AOC, Intel VROC (*1)
- GPU, Accelerator AOC
- DPU
- NVMe
- Account and certificate management
- Network configuration and management
- Virtual media redirection
- BIOS-BMC joint feature
- SecureBootDataBase (*2)
- Troubleshooting
- Remote Presence
- Keyboard, Video & Mouse (KVM) Console Redirection with multi language support
- HTML5 web Console Redirection
- Serial over LAN (SOL)
- Media Redirection
- Simultaneous floppy and CD/ DVD redirection
- HTTP, HTTPs, CIFS/SMB support via Redfish or BMC Web GUI
- KVM console support
- Event Log and Alerting
- Full SMTP support
- Sensor readings
- SNMP trap
- Email alerts
- Leak detection support
- Directory service
- Direct LDAP support from the device
- Windows Active Directory and Open-LDAP
- Remote Authentication Dial In User Service (RADIUS)
- Network management
- Dedicated or Shared NIC
- Network failover
- VLAN
- FQDN, IPv4, IPv6
- Industrial standard support
- SNMP
- SMTP
- DHCP
- NTP
- DNS, Dynamic DNS
- LLDP (*3)
- Common Information Model (CIM)
- SMASH and CLP support
- WSMAN Support (*4)
- SPDM (*2)
- Web-based configuration
- Full configuration using web UI
- Modern BMC user interface
- Data communication secure through HTTPS
- Dashboard with system information, overall health status and quick links to most used components
- System Component Inventory & Health Monitoring
- Better Firmware Update Experience
- Enhanced Storage Monitoring
- Detailed Power Consumption Information
- Troubleshooting
- Crash Dump (*5)
- Health /System Events
- Crash screen capture (*3)
- Crash video capture (*3)
- Syslog
- Post Snooping
- System diagnostics via SDO (*2)
- Clear CMOS remotely (*10)
- System AC cycle remotely (*10)
- Security
- Hardware Root of trust (RoT) (*6)
- Unique pre-programmed default password (*3)
- User account management and Role-based authority
- IP Access Control
- Port Configuration
- UEFI Secureboot (*3)
- System Lock down
- Disk secure erase of internal storage devices
- Intel® platform-dependent features
- Intel On-demand software license activation (*7)
- Intel Power of System (Psys) power limit control (*2)
- Seamless firmware update (*7)
- Intel Node manager offload to BMC (*8)
- Intel PMT and CUPS (*8)
- AMD® platform-dependent features
- AMD iHDT support (*9)
*1 Feature can be supported on X12 only
*2 Feature can be supported on X14/H14 and X13/H13 only
*3 Feature can be supported on X14/H14, X13/H13 and X12/H12 only
*4 Feature can be supported X11/H11/X10 only
*5 Feature can be supported on X13/X12 only
*6 Feature can be supported on AST2600 only
*7 Feature can be supported on X13 only
*8 Feature can be supported on X14 only
*9 Feature can be supported on H14 only
*10 Feature can be supported on X14/H14 only
