Supermicro® トータルソリューション:Canonical OpenStack

Canonical OpenStack は、OpenStack クラウドを設計、導入、管理、拡張、アップグレードする、最も簡単な方法を提供します。

Supermicro と Canonical は、OpenStack 展開において最も一般的なプラットフォームである Ubuntu と、OpenStack を提供するために提携しています。Canonical は、OpenStack ファウンデーションリリースとエンタープライズに、OpenStack の高品質なリリースを提供することで OpenStack に取り組んでいます。

Supermicro Canonical OpenStack 認定プラットフォーム

Supermicro と Canonical を使することで、OpenStack クラウド構築の 70% 以上を実現できます。

OpenStack rack diagram

主な特徴

  • 検証済みのリファレンスアーキテクチャ
  • 認定コンポーネント
  • スケールアウト - 1ラックから複数ラックへ
  • クラウドのための最もグリーンなサーバー - サーバーごとに数百ドル節約
  • 最低コスト-最良のパフォーマンス/ワット/コスト/設置面積
  • 専門的なサポートとサービスを活用してプロとしてスタート

OpenStack のエンタープライズサポートは、お客様がどこからでもグローバルな知識と専門知識のプールにアクセスできるように、Supermicro との提携によって Canonical が提供します。パートナーシップでは以下を提供します:

  • ディスカバリーとデザインサービス – お客様のサイト、データセンター、パートナーからホスティングされているクラウド環境において、必要なサイズや仕様に合わせて設計します。
  • ブートスタックサービス ー当社の専門家が、新しいクラウド環境の展開から、管理、24 時間監視までサポートします。
  • 移行管理-クラウド環境の管理を自社に移行する場合に、スムーズな業務移行を行うためにチームを訓練します。

SKU 詳細

 Value OptionPerformance OptionSecure OptionSingle Socket Performance OptionQty
Components Used
Infrastructure NodeSYS-6019U-TN4RTSYS-6019U-TN4RTSYS-6019U-TN4RTAS -1114S-WTRT3
Cloud NodeSYS-6029U-TR4T*SYS-6029U-TR4T*SYS-2029U-TR4T*AS -2013S-C0R9
Cloud Node Data DisksSATA 7200 RPMU.2 NVMeSATA SSDSAS 7200RPM

54 (6 Per Value Node)
or
27 (3 Per Peformance Node)
or
216 (24 Per Secure Node)
or
54 (6 Per UP Performance Node)

HDD-T6000-ST6000NM0115
(6TB 3.5" SATA3 7200RPM)
HDS-IUN2-SSDPE2KX020T8
(2TB NVMe PCIe 3.0)
HDS-I2T0-SSDSC2KB960G8HDD-A8000-ST8000NM0075 (8TB 3.5" SAS3 7200RPM)
Services
Ubuntu Advantage for OpenStack12
Supermicro Cloud DataCenter Design, Validation and Bootstrapping Service12
Supermicro Rack Integration Service*1
Supermicro Onsite Support1
* 各オプションの正確な CPU、メモリ、その他のシステム要件については、下記の「認定ノード構成」の詳細を参照してください。
** ラッキング&ケーブリング(3rd パーティ製スイッチ); ラッキング&ケーブリング設計図; Supermicro は 3rd パーティ製スイッチを用いた構成には責任を負いません。

ネットワークオプション(10、25、40GB データスイッチ)

標準構成には、2 種類のイーサネットスイッチがあります。1 つは管理/IPMI を統合したトラフィック用、もう1つはデータトラフィック用のネットワークです。管理スイッチは、3つのシステムオプションすべてに共通です。データスイッチのオプションは、"Value" オプションの 10Gbps スイッチから、"Balanced" オプションの 25Gbps スイッチ、"Performance" オプションの 40Gbps スイッチまで用意しています。

 10 GbE Data Network with Cumulus OS325 GbE Data Network with SMIS OS40 GbE Data Network with Cumulus OS3Qty
Management SwitchSSE-G3648BRSSE-G3648BRSSE-G3648BR2 (per rack)
Data SwitchSSE-X3648SRSSE-F3548SRSSE-C3632SR2 (per rack)
Infrastructure Node NICsAOC-STGF-I2S-OAOC-S25G-M2SAOC-S40GI2Q6
(2 Per Node x3)
Cloud Node NICsAOC-STGF-I2S-OAOC-S25G-M2SAOC-S40GI2Q18
(2 Per Node x9)
Software Licenses (for networking)
Management Switch Software perpetual license with 3 yr service /supportSFT-CLSNWPL-1G-3Y1SFT-SMCPL1G2SFT-CLSNWPL-1G-3Y12
Data Switch Software perpetual license with 3 yr service /supportSFT-CLSNWPL-10G-3Y1Included with switch2SFT-CLSNWPL-100G-3Y12

1 – The 10 GbE データスイッチと、40 GbE データスイッチオプションは、ソリューション内のすべてのスイッチに Cumulus OS が必要です。データスイッチと管理スイッチの両方の Cumulus OS ライセンスは、付属の SKU を使用して Supermicro から取得します。

2 – 25 GbEデータスイッチオプションは、ソリューション内のすべてのスイッチに Supermicro(SMIS)OS が必要です。管理スイッチの SMIS OS は、提供される SKU を使用して取得します。データスイッチ用の SMIS OS はスイッチに含まれています。

3 – Cumulus Linux は強力なオープンネットワークオペレーティングシステムで、自動化、カスタマイズ、拡張が可能です:
www.cumulusnetworks.com/products/cumulus-linux/

購入可能な追加サービス

Additional Services
Supermicro Onsite Integration Service*
Ubuntu Advantage Server - Essential / Standard / Advanced Server
Ubuntu Advantage OpenStack Cloud Region
Ubuntu Advantage Professional Service
Ubuntu Bootstack Program
Ubuntu BootStack Professional Services
Ubuntu Advantage Travel & Expenses

* SOW オンサイト調査が必要; オンサイトロジスティクス; ラッキング&ケーブリング(サードパーティ製スイッチ); ラッキング&ケーブリング設計図

Canonical OpenStack 関連のソリューションについては、Supermicro-OpenStack ソリューションチームにお問い合わせください。完全なテストや認証なしに個別に購入した部品は、Canonical OpenStack ソリューションには適さない可能性があります。互換性の問題を回避するために Canonical OpenStack 関連製品の上記の適切なサービスと保証を購入することをお勧めします。上記のすべてのサービスが必須というわけではありません。Supermicro のソリューションチームは、いつでも適切なソリューションを構築するお手伝いをします。

Network Component Details

(Cluster Role: Data Switch)
  • 48x 10Gb Ethernet ports - SFP+
  • 6x 40 Gb Ethernet ports - QSFP+
  • RJ-45 (for console cable)
  • RJ-45 1G Ethernet Management Port
  • USB
  • Switching Capacity: 1440 Gbps
  • Wire-speed Layer 3 Routing
  • 1:1 Non-blocking connectivity
  • Regular Airflow option available
  • Dual redundant hot-swappable power supplies
  • 1U form factor
(Cluster Role: Data Switch)
  • 48x 25Gb Ethernet ports - SFP28
  • 6x 100Gb Ethernet ports - QSFP28
  • RJ-45 (for console cable)
  • RJ-45 1G Ethernet Management Port
  • USB
  • Switching Capacity: 3.6 Tb
  • 1:1 Non-blocking connectivity
  • Regular Airflow option available
  • Dual redundant hot-swappable power supplies
  • 1U form factor
(Cluster Role: Data Switch)
  • 32x Ethernet QSFP28 ports – either 40Gbps or 100Gbps
  • 1x 10Gb Ethernet SFP+ port
  • RJ-45 Gb Ethernet management port
  • RJ-45 serial console
  • Type A USB 2.0 port
  • Full Duplex 3.2Tbps Switching Capacity
  • Regular Airflow option available
  • Dual redundant hot-swappable power supplies
  • 1U form factor
(Cluster Role: Management Switch)
  • 48x 1Gbps Ethernet RJ45 ports
  • 4x 10Gbps Ethernet SFP+ ports
  • RJ-45 Gb Ethernet management port (for console cable)
  • Type A USB 2.0 port
  • Aggregated switching Capacity - 176 Gbps
  • Non-blocking, wire-speed Layer 3 Routing
  • Regular Airflow option available
  • Second (redundant) hot-swappable power supply - optional
  • 1U form factor

Supermicro Canonical OpenStack クラウドは、テストと検証済みのリファレンスアーキテクチャにおいて、さまざまな構成をサポートしています。Canonical は、認定された Supermicro プラットフォーム上での展開において、Canonical OpenStack が「確実に動作する」ことを保証します。お客様には、OpenStack の専門知識レベルに応じたオプションがあります。ブートスタックは、OpenStack をスピードアップさせるために、完全に管理された OpenStack オペレーションをすぐに稼働できる状態で納品します。 経験豊富な OpenStack のお客様に対しては、Canonical & Supermicro から独立してサポートするために、OpenStack クラウドを構築、管理、拡張、アップグレードするための Canonical ツールの使用方法に関するトレーニングサービスを提供します。

Certified Nodes for Canonical OpenStack

(Cluster Role: Infrastructure Node)
  • 28 (2 * 14) Cores
  • 384 (12 * 32) GB RAM
  • 12 TB (2x 6TB) SATA HDD
  • Intel DC P4510 500GB, NVMe PCI-E 3.1 (Cache)
  • 2 RJ45 10GBase-T Ethernet ports
(Cluster Role: "Performance" Cloud Node)
  • 36 (2 * 18) Cores
  • 512 (16 * 32) GB RAM
  • 12TB (2x 6TB) SATA HDD
  • Intel DC P4610 1.6TB NVMe PCI-E 3.1 (Cache)
  • 4 RJ45 10GBase-T Ethernet ports
  • Make sure to add data disks and "NICs for data" separately, per above chart
(Cluster Role: "Value" Cloud Node)
  • 32 (2 * 16) Cores
  • 384 (12 * 32) GB RAM
  • 12 TB (2x 6TB) SATA HDD
  • Intel DC P4610 1.6TB NVMe PCI-E 3.1 (Cache)
  • 4 RJ45 10GBase-T Ethernet ports
  • Make sure to add data disks and "NICs for data" separately, per above chart
(Cluster Role: "Secure" Cloud Node)
  • 40 (2 * 20) Cores
  • 1536 (24 * 64) GB RAM
  • 1 TB (2x 512GB) NVMe SSD
  • 4 RJ45 10GBase-T Ethernet ports
  • Make sure to add data disks and "NICs for data" separately, per above chart
(Cluster Role: Single Socket Performance Infrastructure Node)
  • 48 Cores
  • 128 (8 * 16) GB RAM
  • 15.2 TB (2x 7.6TB) SAS SSD
  • 3.8 TB (1x 3.8TB) NVMe SSD
  • 2 RJ45 10GBase-T Ethernet ports
(Cluster Role: Single Socket Performance Cloud Node)
  • 48 Cores
  • 512 (8 * 64) GB RAM
  • 16 TB (2x 8TB) SAS3 HDD
  • 2 TB (1x 2TB) M.2 NVMe SSD
  • 2 RJ45 1GBase-T Ethernet ports
  • Make sure to add data disks and "NICs for data" separately, per above chart

Supermicro® Secure OpenStack Solution

Protecting sensitive data against cyber security threats is becoming a challenging task of every IT professional. Software-only defense options such as perimeter firewalls are no longer sufficient against threats that target deeper layers of the platform stack. A comprehensive, multi-layered full stack approach is needed to safeguard high-value, sensitive data by ensuring every component of the platform is in a known, trusted state.

Supermicro, Intel, Lockheed Martin, and Canonical have partnered to create a unique Secure OpenStack Solution that offers robust security from boot through runtime with high QoS (Quality of Service) and deterministic performance supporting virtualized environments. This hyper-converged solution provides end users with the full range of attribute based security controls and security policies that can be signed by individual tenants or cloud service providers. Because this solution is based on the Intel Select Solution for Hardened Security with Lockheed Martin, the entire compute/storage cluster is secured from boot to application by Chain of Trust and provides a strengthened approach to:

  • Protect the most sensitive applications and data at the edge of cloud and in data centers
  • Address a broad class of threats with growing sophistication by utilizing proactive security isolation
  • Provide a preservation of performance while maximizing security through tenant isolation

This offering, which combines security and quality of service is best suited for secure, deterministic workloads often found in financial services as well as federal and critical infrastructures.

Supermicro Secure OpenStack Certified Platforms

Secure OpenStack rack diagram

Highlights

  • Intel Hardened Security nodes are fully integrated into OpenStack
  • Attributes Based Security Controls Compliant (NIST 800-53 Draft R5)
  • Systems are secured from boot
  • System integrity is maintained at start/reset
  • Virtualized workloads are isolated & protected
  • Security policies can be signed by tenants or Cloud Service Providers

Compatible CPUs for Intel Hardened Security Cloud Node

Processor Number# of CoresCacheBase FrequencyMax TurboTDPtCase
CLX-SP 62482027.50 MB2.50 Ghz3.90 GHz150 W86°C
CLX-SP 82602435.75 MB2.40 GHz3.90 GHz165 W90°C
CLX-SP 82682435.75 MB2.90 GHz3.90 GHz205 W84°C
CLX-SP 82802838.50 MB2.70 GHz4.00 GHz205 W84°C

SKU Details

 Secure OptionQty
Components Used
Infrastructure NodeSYS-6019U-TN4RT3
Cloud NodeSYS-2029U-TR4T*9
Cloud Node Data DisksSATA SSD

216
(24 Per Secure Node)

HDS-I2T0-SSDSC2KB960G8
(960GB SATA SSD)
Services
Ubuntu Advantage for OpenStack12
Supermicro Cloud DataCenter Design, Validation and Bootstrapping Service12
Supermicro Rack Integration Service**1
Supermicro Onsite Support1
* Please consult "Certified Node Configuration" details, below, for exact CPU, memory and other system requirements for each option
** Racking & Cabling (with 3rd party switches); Racking & Cabling Engineering Drawing; Supermicro will not be responsible for 3rd party switch configuration

Networking Options

Standard configurations include two types of Ethernet switches - one for consolidation of management/IPMI traffic and another for use in networking data traffic.

 40 GbE Data Network with Cumulus OS3Qty
Management SwitchSSE-G3648BR1 (per rack)
Data SwitchSSE-C3632SR2 (per rack)
Infrastructure Node NICsAOC-S40GI2Q6
(2 Per Node x3)
Cloud Node NICsAOC-S40GI2Q18
(2 Per Node x9)
Software Licenses (for networking)
Management Switch Software perpetual license with 3 yr service /supportSFT-CLSNWPL-1G-3Y12
Data Switch Software perpetual license with 3 yr service /supportSFT-CLSNWPL-100G-3Y12

1 – The 1GbE Management switch and 40 GbE Data switch require Cumulus OS for all switches in the solution. The Cumulus OS licenses for both the data and management switches are obtained through Supermicro.

2 – Cumulus Linux is a powerful open network operating system that allows you to automate, customize and scale:
www.cumulusnetworks.com/products/cumulus-linux/

Additional Services that can be purchased

Additional Services
Supermicro Onsite Integration Service*
Ubuntu Advantage Server - Essential / Standard / Advanced Server
Ubuntu Advantage OpenStack Cloud Region
Ubuntu Advantage Professional Service
Ubuntu Bootstack Program
Ubuntu BootStack Professional Services
Ubuntu Advantage Travel & Expenses

*Requires SOW Onsite Survey; Onsite logistics; Racking & Cabling (with 3rd party switches); Racking & Cabling Engineering Drawing

Please consult with Supermicro-OpenStack Solution Team for all Canonical OpenStack related solutions. Any parts purchased individually without full testing and certification may not be fit for Canonical OpenStack Solutions. Please be advised to purchase the right services and warranty above for Canonical OpenStack related products to avoid compatibility issues. Please note not every service above is mandatory. Supermicro's solution team is willing to help you build the right solutions, anytime.

Network Component Details (Secure OpenStack)

(Cluster Role: Data Switch)
  • 32x Ethernet QSFP28 ports – either 40Gbps or 100Gbps
  • 1x 10Gb Ethernet SFP+ port
  • RJ-45 Gb Ethernet management port
  • RJ-45 serial console
  • Type A USB 2.0 port
  • Full Duplex 3.2Tbps Switching Capacity
  • Regular Airflow option available
  • Dual redundant hot-swappable power supplies
  • 1U form factor
(Cluster Role: Management Switch)
  • 48x 1Gbps Ethernet RJ45 ports
  • 4x 10Gbps Ethernet SFP+ ports
  • RJ-45 Gb Ethernet management port (for console cable)
  • Type A USB 2.0 port
  • Aggregated switching Capacity - 176 Gbps
  • Non-blocking, wire-speed Layer 3 Routing
  • Regular Airflow option available
  • Second (redundant) hot-swappable power supply - optional
  • 1U form factor

The Supermicro Canonical OpenStack cloud supports various configurations beyond the tested & validated reference architecture. Canonical guarantees that when deployed on any certified Supermicro platform that Canonical OpenStack will "just work". Customers have options depending on their level of expertise with OpenStack. BootStack is a turnkey, fully managed OpenStack operation for those just getting up to speed with OpenStack. For experienced OpenStack customers, we offer training services on how to use Canonical tooling to build, manage, scale & upgrade the OpenStack cloud you support independent of Canonical & Supermicro.

Certified Nodes for Secure OpenStack

(Cluster Role: Infrastructure Node)
  • 28 (2 * 14) Cores
  • 384 (12 * 32) GB RAM
  • 12 TB (2x 6TB) SATA HDD
  • Intel DC P4510 500GB, NVMe PCI-E 3.1 (Cache)
  • 2 RJ45 10GBase-T Ethernet ports
(Cluster Role: "Secure" Cloud Node)
  • 40 (2 * 20) Cores
  • 1536 (24 * 64) GB RAM
  • 1 TB (2x 512GB) NVMe SSD
  • 4 RJ45 10GBase-T Ethernet ports
  • Make sure to add data disks and "NICs for data" separately, per above chart
