GrandTwin UP Serverboard

3rd Gen Intel® Xeon® Scalable processors
Single Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP
Intel® C621A
Up to 4TB 3DS ECC RDIMM, DDR4-3200MHz; Up to 4TB 3DS ECC LRDIMM, DDR4-3200MHz
Up to 2TB Intel® Optane™ Persistent Memory 200 Series, in 16 DIMM slots
1x PCIe 4.0 x8 4C connector (for front I/O module), 4x PCIe 4.0 x8 MCIO connectors
Intel® C621A controller for 6 SATA3 (6 Gbps) ports; RAID 0,1,5,10
M.2 Interface: 2 PCIe 3.0 x4&SATA,M.2 Form Factor: 2280

...

SYS-210GT-HNTF

Specifications

Product SKUs
MBD-X12SPT-G

Processor
CPU	3rd Gen Intel® Xeon® Scalable processors Single Socket Socket P+ (LGA-4189) supported, CPU TDP supports Up to 270W TDP
Core	Up to 40 cores

System Memory
Memory Capacity	16 DIMM slots Up to 2TB Intel® Optane™ Persistent Memory 200 Series Up to 2TB ECC LRDIMM, DDR4-3200MT/s; Up to 2TB 3DS ECC LRDIMM, DDR4-3200MT/s; Up to 2TB ECC RDIMM, DDR4-3200MT/s; Up to 2TB 3DS ECC RDIMM, DDR4-3200MT/s
Memory Type	3200/2933/2666 MT/s ECC , DDR4 LRDIMM, RDIMM
DIMM Sizes	8GB, 16GB, 32GB, 64GB, 128GB, 256GB DCPMM: 64GB, 128GB, 256GB LRDIMM: 64GB, 128GB LRDIMM: 128GB, 256GB RDIMM: 8GB, 16GB, 32GB, 64GB RDIMM: 64GB, 128GB, 256GB
Memory Voltage	1.2V
Error Detection	Corrects single-bit errors

On-Board Devices
Chipset	Intel® C621A
SATA	Intel® C621A controller for 6 SATA3 (6 Gbps) ports; RAID 0,1,5,10
Graphics	1 ASPEED AST2600 BMC port(s)
Network Controllers	N/A

Expansion Slots
PCIe	N/A
M.2	M.2 Interface: 2 SATA/PCIe 3.0 x4, RAID 0 & 1 Form Factor: 2280 Key: M-Key

System BIOS
BIOS Type	AMI UEFI

Management
Software	SuperCloud Composer®、Supermicro Manager (SSM)、Supermicro Manager (SPM)、Supermicro Manager (SUM)、Supermicro 5 (SD5)、Super Diagnostics Offline (SDO)、Supermicro Service (TAS)、SuperServer Assistant (SAA) 新登場！、サードパーティ製ソフトウェア用プラグイン、IPMIユーティリティ
System Management Software	IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support
Power Configurations	Power-on mode for AC power recovery, ACPI Power Management

Security
Hardware	Trusted Platform Module (TPM) 2.0

PC Health Monitoring
Voltage	VBAT, PCH temperature, Memory temperature, CPU temperature, +5V standby, +5V, +3.3V, +12V, +1.8V, VRM temperature, Memory Voltages, CPU thermal trip support
LED	UID/remote UID LED BMC/IPMI Heartbeat LED
Other Features	WOL, UID, RoHS, Node manager support, RoT, NCSI header
FAN	1x 4-pin fan header (up to 1 fan)

Operating Environment
Operating Temperature Range	10°C - 35°C (50°F - 95°F)
Non-Operating Temperature Range	-40°C - 70°C (-40°F - 158°F)
Operating Relative Humidity Range	8% - 90% (non-condensing)
Non Operating Relative Humidity Range	5% - 95% (non-condensing)

Publish Status
0	Published

Resources

Servers (Optimized for X12SPT-G)

SYS-210GT-HNTF

...

Component Options

Software

Documentation

Parts List

X12SPT-G (For SuperServer Only)

Optional Parts
	Part Number	Qty	Description
TPM security module (optional, not included)	AOM-TPM-9670V AOM-TPM-9671V	1 1	SPI capable TPM 2.0 with Infineon 9670 controller with vertical form factor SPI capable TPM 1.2 with Infineon 9670 controller with vertical form factor
