PCIe |
-
1 PCIe 5.0 x8 Right Riser (in x16) slot,
-
1 PCIe 5.0 x32 Left Riser Slot,
-
5 PCIe 5.0 x8 PCIe5.0 MCIO connector
|
M.2 |
-
M.2 Interface: 1 PCIe 3.0 x2
-
Form Factor: 2280/22110
-
Key: M-Key
|
BIOS Type |
|
BIOS Features |
-
ACPI 6.4
-
SMBIOS 3.5 or later
-
UEFI 2.8
|
Software |
-
SuperDoctor® 5, SPM, SUM, SSM, IPMICFG, IPMIView for Linux/Windows, SMCIPMITool, Trusted Platform Module (TPM), Chassis Intrusion Detection
|
Voltage |
-
VBAT, System level control, Supports system management utility, Monitors CPU voltages, Chipset Voltage, Chassis intrusion header, 6 -fan status, +5V standby, +5V, +3.3V, +12V, Memory Voltages
|
LED |
-
UID/Remote UID
-
CPU / System Overheat LED
|
Temperature |
-
Monitoring for CPU and chassis environment
-
CPU thermal trip support
-
Thermal Monitor 2 (TM2) support
-
PECI
|
FAN |
-
6x 4-pin fan headers (up to 6 fans)
-
Fan speed control
-
6 fans with tachometer status monitoring
-
Overheat LED indication
|
Other Features |
-
WOL, UID, Node Manager Support, M.2 NGFF connector, Control of power-on for recovery from AC power loss, Chassis intrusion detection, ACPI power management
|
|
